3.3V 5.0mm x 7mm
LVDS Surface Mount
High Frequency Oscillator
V902
VCXO
The Connor-Winfield, RoHS compliant, V902 is a 3.3V
Surface Mount 5.0 x 7.5mm, Voltage Controlled Crys-
tal Oscillator (VCXO) with LVDS differential outputs
and enable/disable function. The V902 is designed for
use with applications utilizing a PLL system requiring
low jitter and tight frequency stability. No multiplication
schemes are used in this oscillator design. The sur-
face mount package is designed for high-density
mounting and is optimum for mass production.
Operating Specifications
Parameter
Minimum
Nominal
Maximum
Units
Notes
Center Frequency (Fo)
65
-
200
MHz
Operating Temperature Range
0
-
70
°C
Supply Voltage (Vcc)
3.135
3.3
3.465
Vdc
Supply Current (Icc)
-
40
mA
Jitter:
(BW=10Hz to 20 MHz)
-
5
ps RMS
(BW=12kHz to 20 MHz-
-
1
SSB Phase Noise at 10Hz offset
-
-75
-
at 100Hz offset
-
-95
at 1kHz offset
-
-125
-
dBc/Hz
at 10kHz offset
-
-140
-
at 100kHz offset
-
-145
-
Absolute Maximum Ratings
Parameter
Minimum
Nominal
Maximum
Units
Notes
Storage Temperature
-40
-
85
°C
Supply Voltage (Vcc)
-0.5
-
7.0
Vdc
Control Voltage (Vc)
-0.5
-
Vcc+0.5
Vdc
Features:
RoHS Compliant
65 to 200MHz
3.3V Operation
Low Jitter <1pS RMS
Absolute Pull Range (APR): ±50ppm
Temperature Range: 0° to 70°C
Differential LVDS Outputs
Enable / Disable Function
Surface Mount Package
Tape and Reel Packaging
Notes:
1. Absolute pull range (APR) is the minimum guaranteed pull range of the VCXO under all conditions over the lifetime operation. Including calibration @ 25°C,
frequency vs. change in temperature, frequency vs. change in supply voltage, frequency vs. change in load, shock and vibration and aging for ten years.
The APR is referenced to Fo. Positive Transfer Function.
2. Outputs are enabled with no connection on pad 2. When oscillator is disabled both outputs are in high impedance state
3. Vod measured with 100 ohm resistor between the tru output and the complimentary ouput.
Specifications subject to change without notice. All dimensions in inches. Copyright 1998 The Connor-Winfield Corporation
Bulletin
Vx516
Page
1 of 2
Revision
02
Date
27 Oct 2008
US Headquarters:
630-851-4722
European Headquarters:
+353-61-472221
Input Characteristics
Parameter
Minimum
Nominal
Maximum
Units
Notes
Control Voltage Range (Vc)
0.3
1.65
3.0
Vdc
Frequency Pullability (APR)
±50
-
ppm
1
Monotonic Linearity
-10
-
10
%
Input Impedance
-
60K
-
Ohm
Modulation Bandwidth (3dB)
25
-
kHz
Enable Input Voltage - Low (Vil)
-
0.3 Vcc
Vdc
2
Disable Input Voltage - High (Vih) 0.7Vcc
-
LVDS Output Characteristics
Parameter
Minimum
Nominal
Maximum
Units
Notes
Load
-
100
Ohms
3
Output Differential VOltage (Vod)
250
-
450
mV
Duty Cycle at 50% Level
45
50
55
%
Rise / Fall Time 20% to 80%
-
0.6
1.0
nS
Package Characteristics
Package
Hermetically sealed, ceramic package with grounded metal cover.
