Set your site on VICOR at www.vicorpower.com
Vicor Corp. Tel: 800-735-6200, 978-470-2900 Fax: 978-475-6715
Off-Line Front Ends
Rev.1.3
Page 1 of 5
Single Phase (250, 500, 750W)
Three Phase (1.5, 3, 5 kW)
AC Line Input
Strappable 115/230 Vac
208 Vac +20%/–10%
(Wye or Delta, to )
With Range Strap
90 Vac to 135 Vac
N/A
Without Range Strap
180 Vac to 270 Vac
N/A
Line Frequency
47 to 63 Hz (C-Grade)
47 to 440 Hz (I-Grade)
Line Inrush Current
115 Vac Operation
35 A at peak line
230 Vac Operation
67 A at peak line
240 Vac Operation
52 A at peak line
AC Leakage Current
1.9 mA max. at 250 Vac,
3.2 mA max. at 208 Vac, 63 Hz
63 Hz (C- Grade)
Power Factor (at full load)
0.52 to 0.65 (at low line input)
0.9 (typical at nom. line)
Holdup Time (at full load)
Low Line
250 W (60 Hz): 4 ms min.
500, 750 W (60 Hz): 7 ms min.
Nominal Line
250 W (60 Hz): 27 ms min.
20 ms min. (47 Hz)
500, 750 W (60 Hz): 29 ms. min.
AC Fail Warning Time
250W: None
5 ms min.
(at full load)
500, 750W: 6 ms min.
Module Gate Control Output
Called BUS OK
Called Module Enable
(open drain FET, non-isolated,
referenced to –DC output)
ENABLE Active High (FET cutoff)
Active High (FET cutoff)
Vds max. 18 V transorb clamp
Power-up threshold > 227 V
Power up threshold DC bus:
Vds max: 15 V zener clamp
250 W: 216 V, ±12%
500, 750 W: 244, ±3.5%
ENABLE
Inactive state (DC BUS < 190 V ±5%)
Inactive state (DC BUS < 187 Vdc)
Current sinking 100 mA @
.3 Vds max., threshold DC bus
.3Vds max.
250 W: 172 V, ±16%
500, 750 W: 175 V, ±3.5%
AC OK and BUS OK Status
500, 750 W only
AC OK and BUS OK
Outputs (optically isolated,
transistor output; 500 W,
750 W only)
Off State Breakdown
70 Vce max.
Voltage
On State Voltage
.4 Vce (sat.) max. at 1 mA
On State Current
15 mA max.
On State Threshold
80 – 89 Vac
> 210 Vdc/187 Vac
(no load)
Off State Threshold
85 – 76Vac
< 205 Vdc/< 182 Vac
(load dependent)
Conducted EMI/RFI
VDE 0871/FCC part 15, Class B
VDE 0871/FCC part 15, Class A
Dielectric Withstand
AC line (both phases)
AC line (all phases)
to GND or case
1.5 kVAC; 2121 Vdc
Transient Surge Withstand
IEC 61000-4-5, Level 3
Capability (with no
disruption of function)
Common Mode
1.2/50 s, 2 kV,
either polarity
0 to 360 degree phase angle with
respect to AC line
Normal Mode
1.2/50 s, 1 kV pulse,
either polarity
0 to 360 degree phase angle with
respect to AC line
Product Highlights
From AC line in, to highly regulated DC
out, Vicor offers the total design solution
through a complete family of off-line front
end and DC-DC modular power components.
Vicor’s family of off-line front ends
interface VI-260 and VI-J60 series DC-DC
converters, and MegaMods, to 100, 115,
230 or 240 Vac single-phase and 208 Vac
three-phase mains. In addition, front ends
provide conducted EMI/RFI filtering to
FCC/VDE (Class B single-phase, Class A
three-phase), transient surge protection,
active inrush limiting, a BUS OK status
output (suitable for controlling Vicor
DC-DC converter modules via their Gate In
pin) and an AC OK status output for sys-
tem use in the event of loss of the AC line.
Operating Temperature
(Free Convection)
C: 0°C to +50°C (750 W: +45°C)
I: -20°C to +50°C (750 W: +45°C)
Storage Temperature
-40°C to +80°C
Front End Specifications
(typical at T = 25C, nominal line, 75% load, unless otherwise specified)
Features
250 W, 500 W, 750 W, 115/230 Vac
strappable single-phase
1.5, 3, 5 kW, 208 Vac three-phase
20 – 50 mS holdup
UL, CSA, TV, VDE, BABT
FCC/VDE Class B (single-phase)
FCC/VDE Class A (three-phase)
BUS OK, AC OK, DC OK status signal
96 – 98% efficiency
PC and chassis mount
VI-26X, VI-J6X series compatible
CE Marked
Data Sheet
Off-Line Front Ends
Single or Three Phase
Strappable
