W83L519D
PRELIMINARY
The trademarks and intellectual property rights of Memory Stick belong to SONY Corporation
Publication Release Date: Feb. 2002
The trademarks and intellectual property rights of SD belong to SD GROUP
All trademarks and brand names belong to their respective owners
Revision 0.50
13
CR21 (read only)
Bit [7:0]: Device ID number (lower byte)
= 2Xh
CR22 (Default 80h)
Bit 7: SCPWD
=
0
Power down Smart Card interface.
=
1
No Power down.
Bit 6: MSPWD
=
0
Power down Memory Stick interface.
=
1
No Power down.
Bit 5: SDPWD
=
0
Power down SD memory card interface.
=
1
No Power down.
Bit [4:0]: Reserved.
CR23 (Default 00h)
Bit 7: PME_EN. Power management event enable bit.
=
0
PME_L function is disabled.
=
1
Enable to issue a low pulse on PME_L when a power management event occurs.
Bit 6: MSPME_EN. Memory Stick interface power management event enable bit.
=
0
Memory Stick interface power management event is disabled.
=
1
Enable Memory Stick interface power management event to issue a low pulse on
PME_L when PME_EN is also enabled.
Bit 5: SDPME_EN. SD memory card interface power management event enable bit.
=
0
SD memory card interface power management event is disabled.
=
1
Enable SD memory card interface power management event to issue a low pulse on
PME_L when PME_EN is also enabled.
Bit 4: SCPME_EN. Smart Card interface power management event enable bit.
=
0
Smart Card interface power management event is disabled.
=
1
Enable Smart Card interface power management event to issue a low pulse on
PME_L when PME_EN is also enabled.
Bit [3:0]: Reserved.
CR24 (Default 00h)
Bit 7: Reserved.
Bit 6: MSPME_STS. Memory Stick interface power management event status bit.
