W986432DH
- 10 -
Auto Pre-charge Command
If A10 is set to high when the Read or Write Command is issued, then the auto pre-charge function is
entered. During auto pre-charge, a Read Command will execute as normal with the exception that the
active bank will begin to precharge automatically before all burst read cycles have been completed.
Regardless of burst length, it will begin a certain number of clocks prior to the end of the scheduled
burst cycle. The number of clocks is determined by CAS latency.
A Read or Write Command with auto pre-charge cannot be interrupted before the entire burst
operation is completed for the same bank. Therefore, use of a Read, Write, or Precharge Command is
prohibited during a read or write cycle with auto pre-charge. Once the precharge operation has started,
the bank cannot be reactivated until the Precharge time (t
RP
) has been satisfied. Issue of Auto Pre-
charge command is illegal if the burst is set to full page length. If A10 is high when a Write Command
is issued, the Write with Auto Pre-charge function is initiated. The SDRAM automatically enters the
precharge operation one clock delay from the last burst write cycle. This delay is referred to as write
t
DPL
. The bank undergoing auto pre-charge cannot be reactivated until t
DPL
and t
RP
are satisfied. This is
referred to as t
DAL
, Data-in to Active delay (t
DAL
= t
WR
+ t
RP
). When using the Auto Pre-charge
Command, the interval between the Bank Activate Command and the beginning of the internal
precharge operation must satisfy t
RAS
(min).
Precharge Command
The Precharge Command is used to precharge or close a bank that has been activated. The
Precharge Command is entered when CS, RAS and WE are low and CAS is high at the
rising edge of the clock. The Precharge Command can be used to precharge each bank separately or
all banks simultaneously. Three address bits, A10, BS0, and BS1 are used to define which bank(s) is
to be precharged when the command is issued. After the Precharge Command is issued, the
precharged bank must be reactivated before a new read or write access can be executed. The delay
between the Precharge Command and the Activate Command must be greater than or equal to the
Precharge time (t
RP
).
Self Refresh Command
The Self Refresh Command is defined by having CS, RAS, CAS and CKE held low with WE
high at the rising edge of the clock. All banks must be idle prior to issuing the Self Refresh Command.
Once the command is registered, CKE must be held low to keep the device in Self Refresh mode.
When the SDRAM has entered Self Refresh mode all of the external control signals, except CKE, are
disabled. The clock is internally disabled during Self Refresh Operation to save power. The device will
exit Self Refresh operation after CKE is returned high. A minimum delay time is required when the
device exits Self Refresh Operation and before the next command can be issued. This delay is equal
to the t
AC
cycle time plus the Self Refresh exit time.
If, during normal operation, AUTO REFRESH cycles are issued in bursts (as opposed to being evenly
distributed), a burst of 4,096 AUTO REFRESH cycles should be completed just prior to entering and
just after exiting the self refresh mode.
Power Down Mode
The Power Down mode is initiated by holding CKE low. All of the receiver circuits except CKE are
gated off to reduce the power. The Power Down mode does not perform any refresh operations,
therefore the device can not remain in Power Down mode longer than the Refresh period (t
REF
) of the
device.
