4
White Electronic Designs Corporation Phoenix AZ (602) 437-1520
White Electronic Designs
WEDPN16M64V-XBX
Read and write accesses to the SDRAM are burst oriented; ac-
cesses start at a selected location and continue for a programmed
number of locations in a programmed sequence. Accesses
begin with the registration of an ACTIVE command which is then
followed by a READ or WRITE command. The address bits reg-
istered coincident with the ACTIVE command are used to se-
lect the bank and row to be accessed (BA0 and BA1 select the
bank, A0-12 select the row). The address bits (A0-8) registered
coincident with the READ or WRITE command are used to select
the starting column location for the burst access.
Prior to normal operation, the SDRAM must be initialized. The
following sections provide detailed information covering de-
vice initialization, register definition, command descriptions and
device operation.
SDRAMs must be powered up and initialized in a pre-
defined manner. Operational procedures other than those
specified may result in undefined operation. Once power
is applied to VDD and VDDQ (simultaneously) and the
clock is stable (stable clock is defined as a signal cycling
within timing constraints specified for the clock pin), the
SDRAM requires a 100s delay prior to issuing any com-
mand other than a COMMAND INHIBIT or a NOP. Starting
at some point during this 100s period and continuing at
least through the end of this period, COMMAND INHIBIT
or NOP commands should be applied.
Once the 100s delay has been satisfied with at least one COM-
MAND INHIBIT or NOP command having been applied, a
PRECHARGE command should be applied. All banks must be
precharged, thereby placing the device in the all banks idle state.
Once in the idle state, two AUTO REFRESH cycles must be
performed. After the AUTO REFRESH cycles are complete, the
SDRAM is ready for Mode Register programming. Because the
Mode Register will power up in an unknown state, it should be
loaded prior to applying any operational command.
The Mode Register is used to define the specific mode of
operation of the SDRAM. This definition includes the selec-tion
of a burst length, a burst type, a CAS latency, an operating mode
and a write burst mode, as shown in Figure 3. The Mode Register
is programmed via the LOAD MODE REGISTER command and will
retain the stored information until it is programmed again or the
device loses power.
Mode register bits M0-M2 specify the burst length, M3 specifies
the type of burst (sequential or interleaved), M4-M6 specify the
CAS latency, M7 and M8 specify the operating mode, M9
specifies the WRITE burst mode, and M10 and M11 are reserved
for future use. Address A12 (M12) is undefined but should be
driven LOW during loading of the mode register.
The Mode Register must be loaded when all banks are idle, and
the controller must wait the specified time before initiating the
subsequent operation. Violating either of these requirements
will result in unspecified operation.
Read and write accesses to the SDRAM are burst oriented, with
the burst length being programmable, as shown in Figure 3. The
burst length determines the maximum number of column loca-
tions that can be accessed for a given READ or WRITE command.
Burst lengths of 1, 2, 4 or 8 locations are available for both the
sequential and the interleaved burst types, and a full-page burst
is available for the sequential type. The full-page burst is used
in conjunction with the BURST TERMINATE command to generate
arbitrary burst lengths.
Reserved states should not be used, as unknown operation or
incompatibility with future versions may result.
When a READ or WRITE command is issued, a block of columns
equal to the burst length is effectively selected. All accesses for
that burst take place within this block, meaning that the burst will
wrap within the block if a boundary is reached. The block is
uniquely selected by A1-8 when the burst length is set to two; by
A2-8 when the burst length is set to four; and by A3-8 when the
burst length is set to eight. The remaining (least significant) address
bit(s) is (are) used to select the starting location within the block.
Full-page bursts wrap within the page if the boundary is reached.
Accesses within a given burst may be programmed to be either
sequential or interleaved; this is referred to as the burst type and
is selected via bit M3.
The ordering of accesses within a burst is determined by the
burst length, the burst type and the starting column address, as
shown in Table 1.
FUNCTIONAL DESCRIPTION
REGISTER DEFINITION
MODE REGISTER
INITIALIZATION
BURST LENGTH
BURST TYPE
The 1Gb SDRAM is designed to operate in 3.3V, low-power
memory systems. An auto refresh mode is provided, along
with a power-saving, power-down mode.
All inputs and outputs are LVTTL compatible. SDRAMs offer
substantial advances in DRAM operating performance, in-
cluding the ability to synchronously burst data at a high data
rate with automatic column-address generation, the ability
to interleave between inter nal banks in order to hide
precharge time and the capability to randomly change col-
umn addresses on each clock cycle during a burst access.
