X9271
Characteristics subject to change without notice.
13 of 23
REV 1.2 4/13/04
www.xicor.com
ABSOLUTE MAXIMUM RATINGS
Temperature under bias ................... –65
°C to +135°C
Storage temperature ........................ –65
°C to +150°C
Voltage on SCK any address input
with respect to VSS..................................–1V to +7V
V = |(VH–VL)|...................................................... 5.5V
Lead temperature (soldering, 10 seconds)........ 300
°C
IW (10 seconds).................................................. ±6mA
COMMENT
Stresses above those listed under “Absolute Maximum
Ratings” may cause permanent damage to the device.
This is a stress rating only; the functional operation of
the device (at these or any other conditions above
those listed in the operational sections of this
specication) is not implied. Exposure to absolute
maximum rating conditions for extended periods may
affect device reliability.
RECOMMENDED OPERATING CONDITIONS
Temp
Min.
Max.
Commercial
0
°C
+70
°C
Industrial
–40
°C
+85
°C
Device
Supply Voltage (VCC)
(4) Limits
X9271
5V
±10%
X9271-2.7
2.7V to 5.5V
ANALOG CHARACTERISTICS (Over recommended industrial operating conditions unless otherwise stated.)
Notes: (1) Absolute linearity is utilized to determine actual wiper voltage versus expected voltage as determined by wiper position when used
as a potentiometer.
(2) Relative linearity is utilized to determine the actual change in voltage between two successive tap positions when used as a
potentiometer. It is a measure of the error in step size.
(3) MI = RTOT / 255 or (RH – RL) / 255, single pot
(4) During power up VCC > VH, VL, and VW.
(5) n = 0, 1, 2, …,255; m =0, 1, 2, …., 254.
Symbol
Parameter
Limits
Test Conditions
Min.
Typ.
Max.
Units
RTOTAL
End to End Resistance
100
k
T version
RTOTAL
End to End Resistance
50
k
U version
End to End Resistance
Tolerance
±20
%
Power Rating
50
mW
25
°C, each pot
IW
Wiper Current
±3
mA
RW
Wiper Resistance
300
IW = ± 3mA @ VCC = 3V
RW
Wiper Resistance
150
IW = ± 3mA @ VCC = 5V
VTERM
Voltage on any RH or RL Pin
VSS
VCC
VVSS = 0V
Noise
-120
dBV
/ Hz
Ref: 1V
Resolution
0.4
%
Absolute Linearity(1)
±1
MI(3)
Rw(n)(actual) – Rw(n)(expected)
(5)
Relative Linearity(2)
±0.2
MI(3)
Rw(n + 1) – [Rw(n) + MI]
(5)
Temperature Coefficient of
RTOTAL
±300
ppm/
°C
Ratiometric Temp. Coefficient
20
ppm/°C
CH/CL/CW
Potentiometer Capacitancies
10/10/25
pF
See Macro model
