Product catalogue | Terminals | Screwing technology | SAK-series modular terminals | TS 15 | Feed-through terminals
- 2 -
CSA rating data
Min. cross-section (CSA)
AWG 24
Max. cross-section (CSA)
AWG 16
Conductors for clamping (additional
connection)
Type of connection
---
Flexible with ferrule, min. (DIN 46228 pt 1)
0.5 mm
Flexible with ferrule, max. (DIN 46228 pt 1)
1.5 mm
Conductors for clamping (rated connection)
Clamping range, min.
0.21 mm
Clamping range, max.
2.5 mm
Type of connection
Screw connection
2nd type of connection
screwed
Connection direction
on side
No. of connections
2
Stripping length
7 mm
Clamping screw
M 2.5
Blade size
3.0 x 0.5 mm
Tightening torque range
0.4...0.6 Nm
Torque level with DMS electric screwdriver
1
Gauge to IEC 60947-1
A1
Solid, min.
0.5 mm
Solid, max.
2.5 mm
Stranded, min.
1.5 mm
Stranded, max.
1.5 mm
Flexible, min.
0.5 mm
Flexible, max.
1.5 mm
Flexible with ferrule, min. (DIN 46228/1)
0.5 mm
Flexible with ferrule, max. (DIN 46228/1)
1.5 mm
Flexible, min., ferrule with plastic collar (DIN
46228 pt 4)
0.5 mm
Flexible, max., ferrule with plastic collar (DIN
46228 pt 4)
1.5 mm
Twin wire-end ferrule, min.
0.5 mm
Twin wire end ferrule, max.
0.75 mm
AWG conductor size, min.
AWG 24
AWG conductor size, max.
AWG 14
AWG conductor size, min.
0.21 mm
AWG conductor size, max.
2.08 mm
Dimensions
Width
5.1 mm
Height of lowest version
25 mm
Length
24.8 mm
Weight
3.58 g
TS 15 offset
12.4 mm
Disconnect terminals
Torque level with DMS electric screwdriver
1
