Product catalogue | Terminals | Screwing technology | SAK-series modular terminals | TS 15 | Feed-through terminals
- 3 -
Rating data
Rated cross-section
1.5 mm
Rated voltage
250 V
Rated impulse voltage
4 kV
Rated current
17.5 A
Standards
IEC 60947-7-1
Current with max. conductor
24 A
Pollution severity
3
UL rating data
Voltage (UL)
150 V
Current (UL)
15 A
Min. cross-section (UL)
AWG 22
Max. cross-section (UL)
AWG 14
Approvals
Approvals institutes
Classifications
ETIM 2.0
EC001283
ETIM 3.0
EC001283
eClass 4.1
27-14-11-20
eClass 5.0
27-14-11-20
eClass 5.1
27-14-11-20
Similar products
Order No.
Part designation
Version
0340460000
AKZ 1.5
Feed-through terminal, 1.5 mm, Screw connection, Polyamide,
beige, TS 15
0697160000
AKZ 2.5
Feed-through terminal, 2.5 mm, Screw connection, PA 66, beige,
TS 15
0697180000
AKZ 2.5 BL
Feed-through terminal, 2.5 mm, Screw connection, PA 66, blue, TS
15
0294360000
AKZ 4
Feed-through terminal, 4 mm, Screw connection, Polyamide, beige,
TS 15
0294380000
AKZ 4 BL
Feed-through terminal, 4 mm, Screw connection, Polyamide, blue,
TS 15
