LT1374
1374fb
APPLICATIO
S I
FOR
ATIO
U
saturation), average current (to limit heating), and fault
current (if the inductor gets too hot, wire insulation will
melt and cause turn-to-turn shorts). Keep in mind that
all good things like high efficiency, low profile, and high
temperature operation will increase cost, sometimes
dramatically. Get a quote on the cheapest unit first to
calibrate yourself on price, then ask for what you really
want.
5. After making an initial choice, consider the secondary
things like output voltage ripple, second sourcing, etc.
Use the experts in the Linear Technology’s applica-
tions department if you feel uncertain about the final
choice. They have experience with a wide range of
inductor types and can tell you about the latest devel-
opments in low profile, surface mounting, etc.
W
U
U
Many engineers have heard that solid tantalum capacitors
are prone to failure if they undergo high surge currents.
This is historically true, and type TPS capacitors are
specially tested for surge capability, but surge ruggedness
is not a critical issue with the outputcapacitor. Solid
tantalum capacitors fail during very high turn-onsurges,
which do not occur at the output of regulators. High
dischargesurges, such as when the regulator output is
dead shorted, do not harm the capacitors.
Unlike the input capacitor, RMS ripple current in the
output capacitor is normally low enough that ripple cur-
rent rating is not an issue. The current waveform is
triangular with a typical value of 200mA
RMS
. The formula
to calculate this is:
Output Capacitor Ripple Current (RMS):
(
( )( )( )
I
V
V
V
L f V
RIPPLE RMS
OUT
IN
OUT
IN
)
=
)
(
)
0 29
Ceramic Capacitors
Higher value, lower cost ceramic capacitors are now
becoming available in smaller case sizes. These are tempt-
ing for switching regulator use because of their very low
ESR. Unfortunately, the ESR is so low that it can cause
loop stability problems. Solid tantalum capacitor’s ESR
generates a loop “zero” at 5kHz to 50kHz that is instrumen-
tal in giving acceptable loop phase margin. Ceramic
capacitors remain capacitive to beyond 300kHz and usu-
ally resonate with their ESL before ESR becomes effective.
They are appropriate for input bypassing because of their
high ripple current ratings and tolerance of turn-on surges.
Linear Technology plans to issue a design note on the use
of ceramic capacitors in the near future.
OUTPUT RIPPLE VOLTAGE
Figure 3 shows a typical output ripple voltage waveform
for the LT1374. Ripple voltage is determined by the high
frequency impedance of the output capacitor, and ripple
current through the inductor. Peak-to-peak ripple current
through the inductor into the output capacitor is:
Output Capacitor
The output capacitor is normally chosen by its Effective
Series Resistance (ESR), because this is what determines
output ripple voltage. At 500kHz, any polarized capacitor
is essentially resistive. To get low ESR takes volume so
physically smaller capacitors have high ESR. The ESR
range for typical LT1374 applications is 0.05
to 0.2
. A
typical output capacitor is an AVX type TPS, 100
μ
F at 10V,
with a guaranteed ESR less than 0.1
. This is a “D” size
surface mount solid tantalum capacitor. TPS capacitors
are specially constructed and tested for low ESR, so they
give the lowest ESR for a given volume. The value in
microfarads is not particularly critical, and values from
22
μ
F to greater than 500
μ
F work well, but you cannot
cheat mother nature on ESR. If you find a tiny 22
μ
F solid
tantalum capacitor, it will have high ESR, and output ripple
voltage will be terrible. Table 3 shows some typical solid
tantalum surface mount capacitors.
Table 3. Surface Mount Solid Tantalum Capacitor ESR
and Ripple Current
E Case Size
AVX TPS, Sprague 593D
AVX TAJ
D Case Size
AVX TPS, Sprague 593D
C Case Size
AVX TPS
ESR (Max.,
)
0.1 to 0.3
0.7 to 0.9
Ripple Current (A)
0.7 to 1.1
0.4
0.1 to 0.3
0.7 to 1.1
0.2 (typ)
0.5 (typ)
