2SK4019
2008-06-16
2
Electrical Characteristics (Ta = 25°C)
Characteristic
Symbol
Test Condition
Min
Typ.
Max
Unit
Gate leakage current
IGSS
VGS = ±16 V, VDS = 0 V
—
±10
μA
Drain cutoff current
IDSS
VDS = 100 V, VGS = 0 V
—
100
μA
Drainsource breakdown
voltage
V (BR) DSS
ID = 10 mA, VGS = 0 V
100
—
V
Gate threshold voltage
Vth
VDS = 10 V, ID = 1 mA
0.8
—
2.0
V
VGS = 4 V, ID = 2.5 A
—
0.22
0.30
Drainsource ON-resistance
RDS (ON)
VGS = 10 V, ID = 2.5 A
—
0.17
0.23
Ω
Forward transfer admittance
|Yfs|
VDS = 10 V, ID = 2.5 A
2.0
4.5
—
S
Input capacitance
Ciss
—
500
—
Reverse transfer capacitance
Crss
—
80
—
Output capacitance
Coss
VDS = 10 V, VGS = 0 V, f = 1 MHz
—
190
—
pF
Rise time
tr
—
17
—
Turnon time
ton
—
25
—
Fall time
tf
—
50
—
Switching time
Turnoff time
toff
—
195
—
ns
Total gate charge (Gatesource
plus gatedrain)
Qg
—
22
—
Gatesource charge
Qgs
—
15
—
Gatedrain (“Miller”) charge
Qgd
VDD ≈ 80 V, VGS = 10 V, ID = 5 A
—
7
—
nC
SourceDrain Ratings and Characteristics (Ta = 25°C)
Characteristic
Symbol
Test Condition
Min
Typ.
Max
Unit
Continuous drain reverse current
(Note 1)
IDR
—
5
A
Pulse drain reverse current
(Note 1)
IDRP
—
20
A
Forward voltage (diode)
VDSF
IDR = 5 A, VGS = 0 V
—
1.7
V
Reverse recovery time
trr
—
160
—
ns
Reverse recovery charge
Qrr
IDR = 5 A, VGS = 0 V, dIDR / dt = 50 A / μs
—
0.28
—
μC
Marking
K4019
Lot No.
A line indicates
Lead (Pb)-Free Finish
Part No. (or abbreviation code)
≤
≈
Ω
50
Ω
μ
