參數資料
型號: 74F08
廠商: NXP Semiconductors N.V.
英文描述: Quad two-input AND gate(四2輸入與門)
中文描述: 四2輸入與門(四2輸入與門)
文件頁數: 3/8頁
文件大?。?/td> 70K
代理商: 74F08
Philips Semiconductors
Product specification
74F08
Quad 2-input AND gate
1995 Apr 19
3
ABSOLUTE MAXIMUM RATINGS
(Operation beyond the limits set forth in this table may impair the useful life of the device.
Unless otherwise noted these limits are over the operating free-air temperature range.)
SYMBOL
PARAMETER
RATING
UNIT
V
CC
V
IN
I
IN
V
OUT
I
OUT
Supply voltage
–0.5 to +7.0
V
Input voltage
–0.5 to +7.0
V
Input current
–30 to +5
mA
Voltage applied to output in High output state
–0.5 to V
CC
40
V
Current applied to output in Low output state
mA
T
amb
Operating free air temperature range
Operating free-air temperature range
Commercial range
0 to +70
°
C
Industrial range
–40 to +85
°
C
°
C
T
stg
Storage temperature range
–65 to +150
RECOMMENDED OPERATING CONDITIONS
SYMBOL
PARAMETER
LIMITS
UNIT
MIN
NOM
MAX
V
CC
V
Ih
V
IL
I
IK
I
OH
I
OL
Supply voltage
4.5
5.0
5.5
V
High-level input voltage
2.0
V
Low-level input voltage
0.8
V
Input clamp current
–18
mA
High-level output current
–1
mA
Low-level output current
20
mA
T
amb
Operating free-air temperature range
O erating free-air tem erature range
Commercial range
0
+70
°
C
°
C
Industrial range
–40
+85
DC ELECTRICAL CHARACTERISTICS
(Over recommended operating free-air temperature range unless otherwise noted.)
SYMBOL
PARAMETER
TEST CONDITIONS
1
LIMITS
TYP
2
UNIT
MIN
MAX
V
OH
High level output voltage
High-level output voltage
V
CC
= MIN, V
IL
= MAX
V
IH
= MIN, I
OH
= MAX
V
CC
= MIN, V
IL
= MAX
V
IH
= MIN, I
Ol
= MAX
V
CC
= MIN, I
I
= I
IK
±
10%V
CC
±
5%V
CC
±
10%V
CC
±
5%V
CC
2.5
V
2.7
3.4
V
V
OL
Low level output voltage
Low-level output voltage
0.30
0.50
V
0.30
0.50
V
V
IK
Input clamp voltage
–0.73
–1.2
V
I
I
Input current at maximum input
voltage
V
CC
= MAX, V
I
= 7.0V
100
μ
A
I
IH
I
IL
I
OS
High-level input current
V
CC
= MAX, V
I
= 2.7V
V
CC
= MAX, V
I
= 0.5V
V
CC
= MAX
V
CC
= MAX
V
CC
= MAX
20
μ
A
Low-level input current
Short-circuit output current
3
–0.6
mA
–60
–150
mA
I
CC
Supply current (total)
I
CCH
I
CCL
V
IN
= 4.5V
V
IN
= GND
5.5
8.3
mA
8.6
12.9
mA
NOTES:
1. For conditions shown as MIN or MAX, use the appropriate value specified under recommended operating conditions for the applicable type.
2. All typical values are at V
CC
= 5V, T
amb
= 25
°
C.
3. Not more than one output should be shorted at a time. For testing I
OS
, the use of high-speed test apparatus and/or sample-and-hold
techniques are preferable in order to minimize internal heating and more accurately reflect operational values. Otherwise, prolonged shorting
of a High output may raise the chip temperature well above normal and thereby cause invalid readings in other parameter tests. In any
sequence of parameter tests, I
OS
tests should be performed last.
