February 1995
11
Philips Semiconductors
Preliminary specication
Picture-in-Picture (PIP) controller for NTSC
SAB9075H
PIP modes
The controller contains two independent acquisition-channels which provide the scaling factors to support the range of
different modes. With the external memory of 2 Mbit it is possible to select between single, double and multi-PIP modes.
Table 2 gives an overview of the different PIP modes.
Table 2
PIP modes
Notes
1. The given sub/main sizes are visible PIP sizes, a border is drawn around these PIPs and does not influence these
sizes. The size of the border is 4 pixels wide and 2 lines/fields high.
2. The SAB9075H can be set in automatic mode in which the reduction factors are automatically set by the mode select
and aspect ratio select bits of the I2C-bus. If the automatic mode is switched OFF the reduction factors can be set
manually. This will give more flexibility to adjust the aspect ratios of incoming signals.
PIP positions
The positions are graphically depicted in Figs 5 to 17.
MODE
SUB
MAIN
SUB SIZE(1)
MAIN SIZE(1)
PIXELS
REDUCTION(2)
PIXELS
REDUCTION(2)
4 : 3 main + 4 : 3 sub to 4 : 3 screen or 16 : 9 main + 16 : 9 sub to 16 : 9 screen
1.1
SPS
1
16
160P, 53L
1
4H, 14V
1.2
SPL
1
9
216P, 72L
1
3H, 13V
1.3
DP
1
4
1
4
304P, 108L 1
2H, 12V
304P, 108L 1
2H, 12V
1.4
MP3
3
× 1
16
160P, 53L
1
4H, 14V
1.5
MP4
3
× 1
16
1
4
160P, 53L
1
4H, 14V
304P, 108L 1
2H, 12V
1.6
MP7
7
× 116
160P, 53L
1
4H, 14V
1.7
MP8
7
× 1
16
1
4
160P, 53L
1
4H, 14V
304P, 108L 1
2H, 12V
1.8
MP9
8
× 1
9
1
9
216P, 72L
1
3H, 13V
216P, 72L
1
3H, 13V
16 : 9 sub + 4 : 3 main to 4 : 3 screen
2.1
SPS
1
16
216P, 53L
1
3H, 14V
2.2
SPL
1
9
304P, 72L
1
2H, 13V
4 : 3 sub + 16 : 9 main to 16 : 9 screen
3.1
SPS
1
16
160P, 72L
1
4H, 13V
3.2
DP
1
4
1
4
216P, 108L 1
3H, 12V
304P, 108L 1
2H, 12V
