| 型號： | ARH1617RGS |
| 廠商： | ALLIED COMPONENTS INTERNATIONAL |
| 元件分類： | 脈沖/數據通信變壓器 |
| 英文描述： | DATACOM TRANSFORMER FOR 10/100 BASE-T; ETHERNET APPLICATION(S) |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 2/2頁 |
| 文件大?。?/td> | 358K |
| 代理商： | ARH1617RGS |
15
ALLIED COMPONENTS INTERNATIONAL
714-665-1140
www.alliedcomponents.com
RoHS
01/07/11
Unless otherwise specified all tolerances are:
±0.05 in mm
PCB LAYOUT
SCHEMATICS
ARH1617RGS
Notes:
1. R1-R4=75OHMS,1/16W,5%Resistors.
2. C1=1000pF,2KV Decouping Capacitor.
MATERIALS
ARH1617RGS
Housing: PBT, Flammability Rating 94V-O.
Shell: C2680 Brass, 0.20mm thick, 50u"Min nickel plating.
Mod Jack Contacts: Phosphor Bronze, 0.35mm thick, 6u" Gold plated.
Single Port RJ45 CONNECTOR
WITH INTEGRATED MAGNETICS,TAB DOWN
1CT:1CT
2.5
4
3.0
5
8.
89
11.43
15.49
15.90
2.54
1.27
