4-125
AT-41485 Absolute Maximum Ratings
Absolute
Symbol
Parameter
Units
Maximum[1]
VEBO
Emitter-Base Voltage
V
1.5
VCBO
Collector-Base Voltage
V
20
VCEO
Collector-Emitter Voltage
V
12
IC
Collector Current
mA
60
PT
Power Dissipation [2,3]
mW
500
Tj
Junction Temperature
°C
150
TSTG
Storage Temperature
°C
-65 to 150
Thermal Resistance[2,4]:
θ
jc = 155°C/W
Notes:
1. Permanent damage may occur if
any of these limits are exceeded.
2. TCASE = 25°C.
3. Derate at 6.5 mW/
°C for T
C > 73°C.
4. See MEASUREMENTS section
“Thermal Resistance” for more
information.
Electrical Specifications, TA = 25°C
Symbol
Parameters and Test Conditions
Units
Min.
Typ.
Max.
|S21E|
2
Insertion Power Gain; VCE = 8 V, IC = 25 mA
f = 1.0 GHz
dB
17.5
f = 2.0 GHz
11.5
P1 dB
Power Output @ 1 dB Gain Compression
f = 2.0 GHz
dBm
18.5
VCE = 8 V, IC = 25 mA
G1 dB
1 dB Compressed Gain; VCE = 8 V, IC = 25 mA
f = 2.0 GHz
dB
14.0
NFO
Optimum Noise Figure: VCE = 8 V, IC = 10 mA
f = 1.0 GHz
dB
1.4
1.8
f = 2.0 GHz
1.7
f = 4.0 GHz
3.0
GA
Gain @ NFO; VCE = 8 V, IC = 10 mA
f = 1.0 GHz
dB
17.5
18.5
f = 2.0 GHz
13.5
f = 4.0 GHz
9.5
fT
Gain Bandwidth Product: VCE = 8 V, IC = 25 mA
GHz
8.0
hFE
Forward Current Transfer Ratio; VCE = 8 V, IC = 10 mA
—
30
150
270
ICBO
Collector Cutoff Current; VCB = 8 V
0.2
IEBO
Emitter Cutoff Current; VEB = 1 V
A
1.0
CCB
Collector Base Capacitance[1]: VCB = 8 V, f = 1 MHz
pF
0.25
Notes:
1. For this test, the emitter is grounded.
