September 1988
6
Philips Semiconductors
Product specification
UHF power transistor
BLV91/SL
List of components:
Notes
1.
2.
American Technical Ceramics capacitor type 100A or capacitor of same quality.
Device mounted on a printed-circuit board (see Fig.6).
C1 = C11 = 33 pF multilayer ceramic chip capacitor
C2 = C3 = C10 = 1.4 to 5.5 pF film dielectric trimmer (cat. no. 2222 809 09001)
C4 = C5 = 5.6 pF multilayer ceramic chip capacitor
(1)
C6 = 10 pF multilayer ceramic chip capacitor
C7 = 330 pF multilayer ceramic chip capacitor
C8 = 3.9 pF multilayer ceramic chip capacitor
(1)
C9 = 1.2 to 3.5 pF film dielectric trimmer (cat. no. 2222 809 05001)
L1 = L8 = Ferroxcube wideband HF choke, grade 3B (cat. no. 4312 020 36642)
L2 = 60 nH; 4 turns closely wound enamelled Cu wire (0.4 mm); int. dia. 3 mm; leads 2
×
5 mm
L3 = 50
stripline (25.4 mm
×
2.4 mm)
L4 = 50
stripline (4.4 mm
×
2.4 mm)
L5 = L6 = 34
stripline (14.0 mm
×
4.0 mm)
L7 = 280 nH; 15 turns closely wound enamelled Cu wire (0.4 mm); int. dia. 3 mm; leads 2
×
5 mm
L9 = 50
stripline (24.8 mm
×
2.4 mm)
L10 = 50
stripline (30.5 mm
×
2.4 mm)
R1 = R2 = 10
±
5%; 0.25 W metal film resistor
L3, L4, L5, L6, L9 and L10 are striplines on a double Cu-clad printed-circuit board with P.T.F.E. fibre-glass dielectric
(
ε
r
= 2.2); thickness
1
32
inch; thickness of copper-sheet 2
×
35
μ
m.
