型號： CP-88-11
元件分類： RF連接器
英文描述： CABLE TERMINATED, MALE, BNC CONNECTOR, CRIMP, PLUG
文件頁數： 2/2頁
文件大?。?/td> 71K
代理商： CP-88-11
Cambridge Products, P.O. Box 1732, Waseca, MN 56093-0832 1-800-243.8814 Fax: 507-833-6287 www.cambridgeproducts.com
INCHES (MILLIMETERS)
CUSTOMER DRAWINGS AVAILABLE UPON REQUEST
50 Ohm BNC
Electrical Characteristics
Impedance: 50 Ohm nominal
Frequency range: 0-4 GHz
Working voltage: 500 volts RMS at sea level
Dielectric withstanding voltage: 1500 volts RMS at sea level
Corona level: 375 volts minimum at 70,000 feet
Contact resistance:
Outer - 0.2 milliohms maximum
Center - 2.1 milliohms maximum
Insulation resistance: 5000 megohms minimum
Environmental Characteristics
Recommended temperature range: -55OC to +85OC
Moisture resistance: MIL-STD-202
Mechanical Characteristics
Durability: 500 cycles
Force to engage/disengage: 3 lbs. maximum
Cable retention: 20 lbs., RG-58 C/U cable
Materials
Body: Zinc or brass
Contact: Brass, beryllium copper or phosphor bronze
Spring Washer: Beryllium copper
Crimp sleeve: Brass
Insulator: Delrin or TPX Polymethylpentene
Plating: Body - Nickel (except where noted)
Crimp sleeve - Nickel
Contact - Gold
* These values are typical and may not apply to all connectors.
The BNC series connector is a commercial quality product that intermates with all
standard double bayonet stud BNC designs. All contacts are captivated for rug-
gedness. The 50 ohm and 75 ohm interfaces are intermateable and provide quick,
reliable connections for instrumentation, medical and LAN applications.
BNC Connectors
Specifications
Specifications*
相關PDF資料
PDF描述
CP-88-6 CABLE TERMINATED, MALE, BNC CONNECTOR, CRIMP, PLUG
CP-89-10 CABLE TERMINATED, FEMALE, BNC CONNECTOR, CRIMP, JACK
CP-89-19BM2 PANEL MOUNT, CABLE TERMINATED, FEMALE, BNC CONNECTOR, CLAMP CRIMP/SOLDER, JACK
CP-89-1BM2 PANEL MOUNT, CABLE TERMINATED, FEMALE, BNC CONNECTOR, CLAMP CRIMP/SOLDER, JACK
CP-AD219 MALE-FEMALE, RF STRAIGHT ADAPTER, PLUG-JACK
相關代理商/技術參數
參數描述
CP882 功能描述:CONN BNC PLUG CRIMP RG-59,62 RoHS:是 類別:連接器，互連式 >> 同軸，RF 系列:BNC RoHS指令信息:5221221-2 Statement of Compliance 3D 型號:5221221-2.pdf 標準包裝:1,000 系列:BNC 連接器類型:BNC 連接器類型:插孔，母插口 觸點終端:雙壓接 阻抗:75 歐姆 安裝類型:面板安裝，隔墻式（前端螺母） 緊固型:插銷鎖 纜線組:RG-59，59A，59B 頻率 - 最大:2GHz 特點:- 顏色:- 包裝:散裝
CP-88-2 功能描述:RF 連接器 RG-59 2PC CRIMP PL RoHS:否 制造商:Bomar Interconnect 產品:Connectors 射頻系列:BNC 型式:Jack (Female) 極性: 觸點電鍍:Gold 阻抗: 端接類型:Solder 主體類型:Straight Bulkhead 電纜類型:
CP88-2 制造商:Cambridge Products 功能描述:RF/COAXIAL BNC PLUG STR 50 OHM CRIMP 制造商:Cambridge Products 功能描述:RF/COAXIAL, BNC PLUG, STR, 50 OHM, CRIMP 制造商:Cambridge Products 功能描述:RF/COAXIAL, BNC PLUG, STR, 50 OHM, CRIMP; Series:-; Connector Type:BNC Coaxial; Body Style:Straight Plug; Coaxial Termination:Crimp; Impedance:50ohm; Coaxial Cable Types:RG59, RG62; Contact Plating:Gold; Frequency Max:4GHz ;RoHS Compliant: Yes
CP883 制造商:Emerson Connectivity Solutions 功能描述:Conn; RF; BNC; STR; Cable Plug; 50 Ohms; 2-pc; Crimp; for Belden 8218 cable 制造商:Emerson Connectivity Solutions 功能描述:BNC STRT CRIMP PLUG 2-PIECE BELDEN 8218 制造商:EMERSON NETWORK POWER 功能描述:Conn BNC PL 0Hz to 4GHz 50Ohm Crimp ST Cable Mount Gold
CP-88-3 制造商:Johnson Components 功能描述:CONN BNC PL 0HZ TO 4GHZ 50OHM CRMP ST CBL MNT AU - Bulk 制造商:Cambridge Products 功能描述:Conn BNC PL 0Hz to 4GHz 50Ohm Crimp ST Cable Mount Gold
