參數資料
型號： CPFI-249-1
元件分類： RF連接器
英文描述： CABLE TERMINATED, FEMALE, UHF CONNECTOR, CRIMP, JACK
文件頁數： 2/2頁
文件大?。?/td> 102K
代理商： CPFI-249-1
Cambridge Products, P.O. Box 1732, Waseca, MN 56093-0832 1-800-243-8814 Fax: 507-833-6287 www.cambridgeproducts.com
INCHES (MILLIMETERS)
CUSTOMER DRAWINGS AVAILABLE UPON REQUEST
UHF Connectors
Specificaitons
STANDARD UHF
Electrical Characteristics
Impedance: Nonconstant
Frequency range: 0-500 MHz
Working voltage: 500 volts RMS at sea level
Dielectric withstanding voltage: 1500 volts RMS at sea level
Insulation resistance: 5000 megohms minimum
Environmental Characteristics
Recommended temperature range: -55OC to +85OC
Mechanical Characteristics
Durability: 500 cycles
Cable retention: 20 lbs., RG-58 C/U cable
Materials
Body and coupling nut: Zinc or brass
Contact: Beryllium copper or brass
Crimp Sleeve: Brass
Insulator: Delrin
Plating: Body - Nickel
Crimp sleeve - Nickel
Contact - Gold or nickel
* These values are typical and may not apply to all connectors.
The UHF connectors are low cost, general purpose units designed for low fre-
quency system applications. These commercial quality connectors are equipped
with threaded coupling interfaces for secure and reliable connections. The Stan-
dard UHF and Mini UHF connectors are not intermateable.
Delrin is a registered trademark of Dupont Corporation.
Specifications*
相關PDF資料
PDF描述
CPFI-259-17 CABLE TERMINATED, MALE, UHF CONNECTOR, CRIMP, PLUG
CPFI-259-1 CABLE TERMINATED, MALE, UHF CONNECTOR, CRIMP, PLUG
CPFI-259-2 CABLE TERMINATED, MALE, UHF CONNECTOR, CRIMP, PLUG
CPFI-56 CABLE TERMINATED, MALE, RF CONNECTOR, TWIST ON, PLUG
CPFI-ETN-22 CABLE TERMINATED, MALE, N CONNECTOR, CRIMP, PLUG
相關代理商/技術參數
參數描述
CPFI2591 制造商:Emerson Connectivity Solutions 功能描述:Conn UHF PL 0Hz to 500MHz ST Cable Mount Gold/Nickel 制造商:EMERSON NETWORK POWER 功能描述:Conn UHF PL 0Hz to 500MHz ST Cable Mount Gold/Nickel
CPFI-259-1 功能描述:RF 連接器 STRAIGHT TWST ON PLG RoHS:否 制造商:Bomar Interconnect 產品:Connectors 射頻系列:BNC 型式:Jack (Female) 極性: 觸點電鍍:Gold 阻抗: 端接類型:Solder 主體類型:Straight Bulkhead 電纜類型:
CPFI25917 制造商:Emerson Connectivity Solutions 功能描述:Conn UHF PL 0Hz to 500MHz ST Cable Mount Gold Over Nickel 制造商:EMERSON NETWORK POWER 功能描述:Conn UHF PL 0Hz to 500MHz ST Cable Mount Gold Over Nickel
CPFI56 制造商:Emerson Connectivity Solutions 功能描述:Conn Type F PL ST Cable Mount 制造商:EMERSON NETWORK POWER 功能描述:Conn Type F PL ST Cable Mount
CPFI-56 功能描述:RF 連接器 TWIST-ON RG-6 RoHS:否 制造商:Bomar Interconnect 產品:Connectors 射頻系列:BNC 型式:Jack (Female) 極性: 觸點電鍍:Gold 阻抗: 端接類型:Solder 主體類型:Straight Bulkhead 電纜類型:
