參數資料
| 型號： | DAC2932PFBT |
| 元件分類： | DAC |
| 英文描述： | DUAL 12-BIT 40MSPS DIGITAL TO ANALOG CONVERTER |
| 中文描述： | 雙通道12位40MSPS數模轉換器 |
| 文件頁數： | 9/24頁 |
| 文件大?。?/td> | 343K |
| 代理商： | DAC2932PFBT |
SBAS279C AUGUST 2003 REVISED OCTOBER 2004
www.ti.com
9
Terminal Functions (continued)
TERMINAL
NAME
IOUT1
IOUT1
AGND
DESCRIPTION
I/O
O
NO.
26
Complementary current ouput of I-DAC1
27
O
Current output of I-DAC1
28
Analog ground of I-DAC
+VA
+VA
AGND
29
Analog supply of I-DAC; 2.7V to 3.3V
30
Analog supply of I-DAC; 2.7V to 3.3V
31
Analog ground of I-DAC
AGND
32
Analog ground of I-DAC
IOUT2
IOUT2
+VAV
NC
33
O
Current output of I-DAC2
34
O
Complementary current ouput of I-DAC2
35
Analog supply of V-DAC; 2.7V to 3.3V
36
No internal connection
VOUT1
VOUT2
VOUT3
VOUT4
AGNDV
37
O
Voltage output of V-DAC1
38
O
Voltage output of V-DAC2
39
O
Voltage output of V-DAC3
40
O
Voltage output of V-DAC4
41
Analog ground of V-DAC
REFV
42
I
Reference voltage input for V-DACs; typically connected to supply (+VAV)
Digital supply of V-DAC; 2.7V to 3.3V
+VDV
PDV
43
44
I
Power-down of V-DACs; active high; a logic high initiates the power-down mode
DIN
45
I
Serial digital input for VDAC; see timing and application sections for details
SCLK
46
I
Clock input of V-DAC
SYNC
47
I
Frame synchronization signal for the serial data at DIN. Refer to timing section for details.
DGNDV
48
Digital ground of V-DAC.
