| 型號： | DG2618DN-T1-E4 |
| 廠商： | Vishay Siliconix |
| 文件頁數： | 5/10頁 |
| 文件大小： | 0K |
| 描述： | IC SWITCH LV DUAL SPST 10DFN |
| 標準包裝： | 2,500 |
| 功能： | 開關 |
| 電路： | 2 x SPDT - NC/NO |
| 導通狀態電阻： | 7 歐姆 |
| 電壓電源： | 單電源 |
| 電壓 - 電源，單路/雙路(±)： | 1.5 V ~ 3.6 V |
| 電流 - 電源： | 100nA |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 10-VFDFN 裸露焊盤 |
| 供應商設備封裝： | 10-DFN（3x3） |
| 包裝： | 帶卷 (TR) |
www.vishay.com
4
Document Number: 74411
S-82149-Rev. B, 08-Sep-08
Vishay Siliconix
DG2616, DG2617, DG2618
Notes:
a. Room = 25 °C, Full = as determined by the operating suffix.
b. The algebraic convention whereby the most negative value is a minimum and the most positive a maximum, is used in this data sheet.
c. Typical values are for design aid only, not guaranteed nor subject to production testing.
d. Guarantee by design, not subjected to production test.
e. VIN = input voltage to perform proper function.
f. Crosstalk measured between channels.
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation
of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum
rating conditions for extended periods may affect device reliability.
Parameter
Symbol
Test Conditions
Otherwise Unless Specified
V+ = 3 V, ± 10 %, VIN = 0.5 or 1.4 V
e
Temp.a
Limits
- 40 °C to 85 °C
Unit
Min.b
Typ.c
Max.b
Power Supply
Power Supply Range
V+
1.5
3.6
V
Power Supply Current
I+
V+ = 3.6 V, VIN = 0 or V+, SHDN/EN = 0 V
Full
104
300
A
V+ = 3.6 V, VIN = 0 or V+, SHDN/EN = V+
0.1
2
SPECIFICATIONS V+ = 3 V
