參數資料
| 型號： | DG2718DN-T1-E4 |
| 廠商： | Vishay Siliconix |
| 文件頁數： | 3/7頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC SWITCH DUAL DPDT 16QFN |
| 標準包裝： | 2,500 |
| 功能： | 開關 |
| 電路： | 2 x DPDT - NC/NO |
| 導通狀態電阻： | 600 毫歐 |
| 電壓電源： | 單電源 |
| 電壓 - 電源，單路/雙路(±)： | 1.65 V ~ 3.6 V |
| 電流 - 電源： | 1µA |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 16-VFQFN 裸露焊盤 |
| 供應商設備封裝： | 16-QFN（3x3） |
| 包裝： | 帶卷 (TR) |
DG2718
Vishay Siliconix
New Product
Document Number: 72677
S–52186—Rev. B, 17-Oct-05
www.vishay.com
3
SPECIFICATIONS (V+ = 3 V)
Test Conditions
Otherwise Unless Specified
Limits
–40 to 85
_C
Parameter
Symbol
V+ = 3 V,
"10%, VIN = 0.5 or 1.4 Ve
Tempa
Minb
Typc
Maxb
Unit
Analog Switch
Analog Signal Ranged
VNO, VNC,
VCOM
Full
0
V+
V
On-Resistanced
rON
V+ = 2.7 V, VCOM = 0.2 V/1.5 V, INO, INC = 100 mA
Room
Full
0.45
0.6
0.7
rON Flatnessd
rON
Flatness
V+ = 2.7 V
V
0toV+ I
I
100 mA
Room
0.1
0.15
W
rON Matchd
DrON
VCOM = 0 to V+, INO, INC = 100 mA
Room
0.05
Switch Off Leakage Current
INO(off),
INC(off)
V+ = 3.3 V, VNO, VNC = 0.3 V/3 V
Room
Full
–1
–10
1
10
Switch Off Leakage Current
ICOM(off)
V+ = 3.3 V, VNO, VNC = 0.3 V/3 V
VCOM = 3 V/0.3 V
Room
Full
–1
–10
1
10
nA
Channel-On Leakage Current
ICOM(on)
V+ = 3.3 V, VNO, VNC = VCOM = 0.3 V/3 V
Room
Full
–1
–10
1
10
Digital Control
Input High Voltage
VINH
Full
1.4
V
Input Low Voltage
VINL
Full
0.5
V
Input Capacitance
Cin
Full
6
pF
Input Current
IINL or IINH
VIN = 0 or V+
Full
–1
1
mA
Dynamic Characteristics
Turn-On Time
tON
Room
Full
28
57
60
Turn-Off Time
tOFF
VNO or VNC = 1.5 V, RL = 50 W, CL = 35 pF
Room
Full
17
45
47
ns
Break-Before-Make Time
td
Full
1
Charge Injectiond
QINJ
CL = 1 nF, VGEN = 0 V, RGEN = 0 W
Room
232
pC
Off-Isolationd
OIRR
RL =50 W CL = 5 pF f = 100 kHz
Room
–75
dB
Crosstalkd
XTALK
RL = 50 W, CL = 5 pF, f = 100 kHz
Room
–75
dB
NO NC Off Capacitanced
CNO(off)
Room
102
NO, NC Off Capacitanced
CNC(off)
VIN =0orV+ f=1MHz
Room
102
pF
Channel On Capacitanced
CNO(on)
VIN = 0 or V+, f = 1 MHz
Room
234
pF
Channel-On Capacitanced
CNC(on)
Room
234
Power Supply
Power Supply Range
V+
2.7
3.3
V
Power Supply Current
I+
VIN = 0 or V+
Full
1.0
mA
Notes:
a.
Room = 25
°C, Full = as determined by the operating suffix.
b.
The algebraic convention whereby the most negative value is a minimum and the most positive a maximum, is used in this data sheet.
c.
Typical values are for design aid only, not guaranteed nor subject to production testing.
d.
Guarantee by design, nor subjected to production test.
e.
VIN = input voltage to perform proper function.
f.
Guaranteed by 5-V leakage testing, not production tested.
