參數資料
| 型號： | DLP-245SY-G |
| 廠商： | DLP Design Inc |
| 文件頁數： | 9/14頁 |
| 文件大小： | 0K |
| 描述： | MODULE USB-MCU FT245RL W/SX48 |
| 產品目錄繪圖： | DLP-245SY-G |
| 標準包裝： | 1 |
| 系列： | USB |
| 模塊/板類型： | 開發板 |
| 適用于相關產品： | USB |
| 其它名稱： | 813-1006 |
4
FT_EE_UASize gets its size, FT_EE_UAWrite writes data into it, and FT_EE_UARead is used to
read its contents.
Download FTDI Application Notes AN232-03, AN232-05, AN232-06, and AN232-07 for
detailed instructions on how to install and remove the drivers.
EEPROM WRITE UTILITY
The DLP-245SY-G has the option to accept manufacturer-specific information that is written into
the EEPROM area of the FT245RL. Parameters that can be programmed include the VID and
the PID identifiers, the manufacturer's product string, and a serial number.
MPROG is the latest EEPROM serializer utility from FTDI for the FT245RL device. MPROG uses
the new D2XX drivers and will work on Windows 98, Windows ME, and Windows 2000/XP
platforms. You must install the latest release of the D2XX drivers in order to run this application.
QUICK START GUIDE
This guide requires the use of a Windows 98/2000/XP PC that is equipped with a USB port.
1. Download the DLL version of the device drivers from either dlpdesign.com or ftdichip.com.
Unzip the drivers onto a blank floppy disk or into a folder on the hard drive.
2. The board can be configured to receive its operating power from the USB port or from user
electronics. Pins 18, 19, and 20 allow for this configuration. (Refer to the Pinout Description
in the next section for a detailed description of the DLP-245SY-G electrical interface.)
Note: The board will not operate until a power source has been selected as mentioned in
Step 2.
3. Connect the DLP-245SY-G board to the PC via a standard A-B, 6-foot USB cable. This
action initiates the loading of the USB drivers. When prompted, select the folder where the
DLL version of the device drivers was stored in Step 1. Windows will then complete the
installation of the device drivers for the DLP-245SY-G. The next time the DLP-245SY-G is
