RipTide PCI Audio/Comm Device Family Product Description
1167
ROCKWELL PROPRIETARY INFORMATION
15
Table 4-1. ACC Pin Signals - 176-Pin TQFP (Cont’d)
Pin
Signal Label
I/O Type1
Interface3
Pin
Signal Label
I/O Type1
Interface
51
AD24
Ip/Opts
PCI: AD24
139
SEEPCLK
Ot4
EEPROM: SK
52
CBE3#
Ip/Opts
PCI: CBE3#
140
SEEPDI
It
EEPROM: DO
53
IDSEL
Ip
PCI: IDSEL
141
VSS
GND
54
AD23
Ip/Opts
PCI: AD23
142
VDD
PWR
+3.3V
55
AD22
Ip/Opts
PCI: AD22
143
TCK
It
JTAG: TCK
56
AD21
Ip/Opts
PCI: AD21
144
TDI
Itpu
JTAG: TDI
57
AD20
Ip/Opts
PCI: AD20
145
TDO
Ot4
JTAG: TDO
58
AD19
Ip/Opts
PCI: AD19
146
TMS
Itpu
JTAG: TMS
59
AD18
Ip/Opts
PCI: AD18
147
TRST#
Itpu
PCI: TRST#
60
AD17
Ip/Opts
PCI: AD17
148
MPLLOUT
Ot2
XTLI
61
VDD
PWR
+3.3V
149
MPLLCAP
GND through 10 uF
62
VSS
GND
150
BIT_CLK
Iacl
AMC: BIT_CLK
63
AD16
Ip/Opts
PCI: AD16
151
BIT_CLKD
Iacl
DS: BIT_CLK
64
CBE2#
Ip/Opts
PCI: CBE2#
152
SDATA_IN
Iacl
AMC: SDATA_IN
65
FRAME#
Ip/Opsts
PCI: FRAME#
153
SDATA_IND
Iacl
DS: SDATA_IN
66
IRDY#
Ip/Opsts
PCI: IRDY#
154
SDATA_OUT
Oacl4
AMC: SDATA_OUT
67
VDD
PWR
+3.3V
155
VDD
PWR
+3.3V
68
VSS
GND
156
VSS
GND
69
TRDY#
Ip/Opsts
PCI: TRDY#
157
SYNC
Oacl4
AMC: SYNC
70
DEVSEL#
Ip/Opsts
PCI: DEVSEL#
158
RESET#
Oacl4
AMC: RESET#
71
STOP#
Ip/Opsts
PCI: STOP#
159
RESETD#
Oacl4
NC
72
PERR#
Ip/Opsts
PCI: PERR#
160
GPI0/IRING#
It
LAI: Ring Detect Circuit
73
SERR#
Opod
PCI: SERR#
161
GPI1/RINGWAKE#
It
LAI: Ring Detect Circuit
74
VDD
PWR
+3.3V
162
GPIO7/VAUXDET
It
PM: VAUXDET
75
VSS
GND
163
GPIO6/VPCIDET
It
PM: VPCIDET
76
PAR
Ip/Opts
PCI: PAR
164
VSS
GND
77
CBE1#
Ip/Opts
PCI: CBE1#
165
VDD
PWR
+3.3V
78
AD15
Ip/Opts
PCI: AD15
166
GPIO5/VAUXEN#
Ot2
PM: VAUXEN#
79
AD14
Ip/Opts
PCI: AD14
167
GPIO4/VPCIEN#
Ot2
PM: VPCIEN# and DSP:
WKRESP
80
AD13
Ip/Opts
PCI: AD13
168
GPIO3/DOCKSENSE
It
NC
81
AD12
Ip/Opts
PCI: AD12
169
GPIO2/VPCIPREFERRED
It
PM: VPCIPREFERRED
82
AD11
Ip/Opts
PCI: AD11
170
GPIO1
It/Ot2
Application assigned
83
VDD
PWR
+3.3V
171
GPIO0
It/Ot2
Application assigned
84
VSS
GND
172
SCANENB
Itpd
NC
85
AD10
Ip/Opts
PCI: AD10
173
SCANMODE
Itpd
NC
86
AD9
Ip/Opts
PCI: AD9
174
GPI2/VOL_UP
Itpu
AI: Volume up control
87
AD8
Ip/Opts
PCI: AD8
175
GPI3/VOL_DWN
Itpu
AI: Volume down control
88
CBE0#
Ip/Opts
PCI: CBE0#
176
GPI4/VOL_MUTE
Itpu
AI: Volume mute control
1. I/O types:
I/Opod
Input/Output, PCI, open drain (PCI type =o/d)
I/Opsts
Input/Output, PCI, sustained tristate (PCI type = s/t/s)
I/Opts
Input/Output, PCI, tristate (PCI type = t/s)
Ia/Oa4
Input, ACL/Output, ACL, 4 mA, 20pF
Ip
Input, PCI, totem pole (PCI type = in)
Ipts
Input, PCI, (PCI type = t/s)
It
Input, TTL
Itpd
Input, TTL, internal pull-down
Itpu
Input, TTL, internal pull-up
It/Ot2
Input, TTL/Output, TTL, 2 mA, 20 pF
It/Ot4
Input, TTL/Output, TTL, 4 mA, 20 pF
It/Ot12
Input, TTL/Output, TTL, 12 mA, 20 pF
Ood
Output, open drain
Opod
Output, PCI, open drain (PCI type =o/d)
Opts
Output, PCI, tristate (PCI type = t/s)
Ot2
Output, TTL, 2 mA, 20 pF
Ot4
Output, TTL, 4 mA, 20 pF
Ot12
Output, TTL, high =12 mA, low = -12 mA, 20 pF.
