ADV7533
Data Sheet
Rev. A | Page 10 of 12
Pin No.
Mnemonic
Type1
Description
G7
A2VDD
P
1.8 V Power Supply for MIPI/DPHY Input. Should be filtered and as quiet as possible.
E2, E4, G1
DVDD
P
1.8 V Power Supply for Digital and I/O Power Supply. Supply power to the digital logic
and I/Os. Should be filtered and as quiet as possible.
C6
PVDD
P
1.8 V Power Supply for the PLL. Should be filtered and as quiet as possible. This supply is
the most noise sensitive.
B1
V3P3
P
3.3 V programming pin for HDCP nonvolatile memory.
B2, B3, B5, B6, C7,
E1, E7, F1, F7
GND
P
Ground for all domains.
E5
SDA
C
Serial Port Data I/O. Serves as the serial port data I/O slave for register access. Supports
CMOS logic levels from 1.8 V to 3.3 V.
E6
SCL
C
Serial Port Data Clock. Serves as the serial port data clock slave for register access.
Supports CMOS logic levels from 1.8 V to 3.3 V.
D2
DDCSDA
C
Serial Port Data I/O to Receiver. Serves as the master to the DDC bus. 5 V CMOS logic
level.
D1
DDCSCL
C
Serial Port Data Clock to Receiver. Serves as the master clock for the DDC bus. 5 V CMOS
logic level.
D6
CEC
I/O
CEC I/O. If unused, pin should be connected to ground.
D7
CEC_CLK
I
CEC External Clock. Can be from 3 MHz to 100 MHz. Settings default to 12 MHz. If
unused, pin should be connected to ground.
1 I = input, O = output, P = power supply, C = control.
