HD74AC175
3
Functional Description
The HD74AC175 consists of four edge-triggered D flip-flops with individual D inputs and Q and
Q
outputs. The Clock and Master Reset are common. The four flip-flops will store the state of their
individual D inputs on the Low-to-High clock (CP) transition, causing individual Q and
Q
outputs to
follow. A Low input on the Master Reset (
MR
) will force all Q outputs Low and
Q
outputs High
independent of Clock or Data inputs. The HD74AC175 is useful for general logic applications where a
common Master Reset and Clock are acceptable.
Truth Table
Inputs
@ t
n
,
MR
= H
Dn
Outputs
@ t
n+1
Qn
Q
n
L
L
H
H
H :
L
t
n
t
n + 1
:
H
L
High Voltage Level
Low Voltage Level
Bit Time before Clock Pulse
Bit Time after Clock Pulse
:
:
Logic Diagram
D
0
D
CP
CD
Q
Q
0Q0
Q
D
1
D
CP
CD
Q
Q
1Q1
Q
D
2
D
CP
CD
Q
Q
2Q2
Q
D
3
CP
MR
D
CP
CD
Q
Q
3Q3
Q
Please note that this diagram is provided only for the understanding of logic operations and should not be
used to estimate propagation delays.
