HD74AC283/HD74ACT283
5
Logic Diagram
C
0
S
0
S
1
S
2
S
3
C
4
A
0
A
1
B
0
B
1
A
2
B
2
A
3
B
3
Please note that this diagram is provided only for the understanding of logic operations and shoudl not be
used to estimate propagation delays.
DC Characteristics
(unless otherwise specified)
Item
Symbol
Max
Unit
Condition
Maximum quiescent supply current
I
CC
80
μ
A
V
= V
or ground, V
CC
= 5.5 V,
Ta = Worst case
Maximum quiescent supply current
I
CC
8.0
μ
A
V
= V
CC
or ground, V
CC
= 5.5 V,
Ta = 25
°
C
Maximum I
CC
/input (HD74ACT283)
I
CCT
1.5
mA
V
= V
– 2.1 V, V
CC
= 5.5 V,
Ta = Worst case
