ISD-300A1
4
October 19, 2001
Pin Name
TQFP
Pin #
Dir
Type
Description
NEJECT
36
I
LVTTL, 5V
tolerant,
hysteresis
Active low. Media eject requested. If remote
wakeup is enabled by the USB host, a state
change on this pin will cause the ISD-300A1 to
perform a USB remote wakeup event. Filtered
internally by ISD-300A1. Set NEJECT = 1 if the
functionality is not utilized.
I
2
C clock. Open drain during normal operation.
This pin may be left as a no-connect pin if the I
2
C
interface is not utilized.
I
2
C address/data. Open drain during normal
operation. An external pull-up resistor is required
for correct operation in all ISD-300A1 modes of
operation.
SCL
97
O
6 mA LVTTL,
5V tolerant
SDA
96
IO
6 mA LVTTL,
5V tolerant
DMARQ
69
I
LVTTL,
5V Fail Safe
ATA control.
NDMACK
61
O
6 mA LVTTL,
5V Fail Safe
ATA control.
DA0 – DA2
56, 59, 55
O
6 mA LVTTL,
5V Fail Safe
ATA Address.
DD0 – DD15
71, 73, 77, 79, 81, 84,
87, 89, 88, 86, 82, 80,
78, 74, 72, 70
IO
6 mA LVTTL,
5V Fail Safe
ATA Data.
NDIOR
64
O
6 mA LVTTL,
5V Fail Safe
ATA control.
NDIOW
65
O
6 mA LVTTL,
5V Fail Safe
ATA control.
NCS0, NCS1
54, 53
O
6 mA LVTTL,
5V Fail Safe
ATA Chip Selects.
IORDY
63
I
LVTTL,
5V Fail Safe
6 mA LVTTL,
5V Fail Safe
ATA control.
ATA_PU_EN
62
O
Active high. ATA IORDY pull-up connection.
Driven low during USB suspend, 3-stated (hi-Z)
when ATA_EN=0.
ATA_PD_EN
67
O
6 mA LVTTL,
5V Fail Safe
Active low. ATA DMARQ pull-down
connection. 3-state (hi-Z) when ATA_EN=0.
NATA_RESET
90
O
6 mA LVTTL,
5V Fail Safe
Active low. ATA reset.
NLED0
95
O
12 mA LVTTL
Active low. LED drive to indicate USB bus
speed. Active when utilizing HS, inactive during
FS or USB suspend or other low power modes of
operation. Open drain during normal operation.
Leave as a no-connect pin if functionality is not
utilized.
NLED1
94
O
12 mA LVTTL
Active low. LED drive to indicate status of
device initialization. Flashing when initializing is
in progress, solid when the device is initialized,
and inactive during USB suspend or other low
power modes of operation. Open drain during
normal modes of operation. Leave as a no-
connect pin if functionality is not utilized.
I_MODE
34
I
LVTTL, 5V
Tolerant
Active high. Indicates ISD-300A1 configuration /
USB descriptor information is obtained using the
ATA vendor specific Identify command (FBh)
USB full speed output buffer (D
). RSDM also
functions as a current sink for termination during
HS operation.
RSDM
16
O
USB IO
