| 型號： | ISL59885 |
| 廠商： | Intersil Corporation |
| 英文描述： | Auto-Adjusting Sync Separator for HD and SD Video(HD和SD視頻專用自動調節同步信號分離器) |
| 中文描述： | 自動調整同步分離器的高清和標清視頻（高清和標清視頻專用自動調節同步信號分離器） |
| 文件頁數： | 4/13頁 |
| 文件大?。?/td> | 361K |
| 代理商： | ISL59885 |
4
FN7442.6
August 15, 2007
FIGURE 7. TIMING DIAGRAM
FIGURE 5. PACKAGE POWER DISSIPATION vs AMBIENT
TEMPERATURE
FIGURE 6. PACKAGE POWER DISSIPATION vs AMBIENT
TEMPERATURE
Typical Performance Curves
(Continued)
JEDEC JESD51-7 HIGH EFFECTIVE THERMAL
CONDUCTIVITY TEST BOARD
0
25
50
75
100
125
150
TEMPERATURE (°C)
85
1.8
P
1.136W
θ
JA
=+110°CW
SOC8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
JEDEC JESD51-3 LOW EFFECTIVE THERMAL
CONDUCTIVITY TEST BOARD
781mW
θ
JA
=+160°CW
SOC8
0
25
50
75
100
125
150
TEMPERATURE (°C)
85
1.2
P
1.0
0.8
0.6
0.4
0.2
0
NOTES:
2. The composite sync output reproduces all the video input sync pulses, with a propagation delay.
3. Vertical sync leading edge is coincident with the first vertical serration pulse leading edge with a propagation delay.
4. Horizontal sync output produces the true “H” pulses of nominal width of 5μs. It has the same delay as the composite sync.
1
2
3
4
5
6
7
8
9
10
19
20
21
3H
3H
3H
VERTICAL BLANKING INTERVAL = 20H
-H1271μs+63.5μs
-0μs
1.5μs ±0.1μs
TIME
9 LINE VERTICAL INTERVAL
PRE-
EQUALIZING
PULSE INTERVAL
VERTICAL SYNC
PULSE INTERVAL
POST-
EQUALIZING
PULSE INTERVAL
H
H SYNC
INTERVAL
START OF
FIELD ONE
H
H
0.5H
H
REF SUBCARRIER PHASE,
COLOR FIELD ONE
SIGNAL 1a. COMPOSITE VIDEO INPUT, FIELD ONE
SIGNAL 1b. COMPOSITE SYNC OUTPUT, PIN 1
SIGNAL 1c. VERTICAL SYNC OUTPUT, PIN 3
SIGNAL 1d. HORIZONTAL SYNC OUTPUT, PIN 7
t
VS
ISL59885
