型號： ISP1160BM
廠商： NXP SEMICONDUCTORS
元件分類： 總線控制器
英文描述： Embedded Universal Serial Bus Host Controller
中文描述： UNIVERSAL SERIAL BUS CONTROLLER, PQFP64
封裝： 7 X 7 MM, 1.40 MM HEIGHT, PLASTIC, MS-026, SOT-414-1, LQFP-64
文件頁數： 27/88頁
文件大?。?/td> 2044K
代理商： ISP1160BM
Philips Semiconductors
ISP1160
Embedded USB Host Controller
Product data
Rev. 04 — 04 July 2003
27 of 88
9397 750 11371
Koninklijke Philips Electronics N.V. 2003. All rights reserved.
However, if communication with a peripheral USB device is desired, the device should
be connected to the downstream port and pass enumeration.
//The example program for writing ATL buffer RAM
#include <conio.h>
#include <stdio.h>
#include <dos.h>
//Define register commands
#define wHcTransferCounter 0x22
#define wHcuPInterrupt 0x24
#define wHcATLBufferLength 0x2b
#define wHcBufferStatus 0x2c
// Define I/O Port Address for HC
#define HcDataPort 0x290
#define HcCmdPort 0x292
//Declare external functions to be used
unsigned int HcRegRead(unsigned int wIndex);
void HcRegWrite(unsigned int wIndex,unsigned int wValue);
void main(void)
{
unsigned int i;
unsigned int wCount,wData;
// Prepare PTD data to be written into HC ATL buffer RAM:
unsigned int PTDData[0x28]
=
{
0x0800,0x1010,0x0810,0x0005, //PTD header for IN token #1
//Reserved space for payload data of IN token #1
0x0000,0x0000,0x0000,0x0000, 0x0000,0x0000,0x0000,0x0000,
0x0800,0x1008,0x0808,0x0005, //PTD header for IN token #2
//Reserved space for payload data of IN token #2
0x0000,0x0000,0x0000,0x0000,
0x0800,0x1010,0x0410,0x0005, //PTD header for OUT token #1
0x0100,0x0302,0x0504,0x0706, //Payload data for OUT token #1
0x0908,0x0b0a,0x0d0c,0x0f0e,
0x0800,0x1808,0x0408,0x0005, //PTD header for OUT token #2
0x0200,0x0604,0x0a08,0x0e0c //Payload data for OUT token #2
};
HcRegWrite(wHcuPInterrupt,0x04); //Clear EOT interrupt bit
//HcRegWrite(wHcITLBufferLength,0x0);
HcRegWrite(wHcATLBufferLength,0x1000); //RAM full use for ATL
//Set the number of bytes to be transferred
HcRegWrite(wHcTransferCounter,0x50);
wCount
=
0x28; //Get word count outport
(HcCmdPort,0x00c1); //Command for ATL buffer write
相關PDF資料
PDF描述
ISP1161A Full-speed Universal Serial Bus single-chip host and device controller
ISP1161ABD Full-speed Universal Serial Bus single-chip host and device controller
ISP1161ABM Full-speed Universal Serial Bus single-chip host and device controller
ISP1161 Full-speed Universal Serial Bus single-chip host and device controller
ISP1161A1 Universal Serial Bus single-chip host and device controller
相關代理商/技術參數
參數描述
ISP1160BM,557 功能描述:USB 接口集成電路 USB 1.1 HOST CONTROLLER RoHS:否 制造商:Cypress Semiconductor 產品:USB 2.0 數據速率: 接口類型:SPI 工作電源電壓:3.15 V to 3.45 V 工作電源電流: 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:WLCSP-20
ISP1160BM/01 制造商:PHILIPS 制造商全稱:NXP Semiconductors 功能描述:Embedded Universal Serial Bus Host Controller
ISP1160BM/01,118 功能描述:USB 接口集成電路 USB HOST CTRL RoHS:否 制造商:Cypress Semiconductor 產品:USB 2.0 數據速率: 接口類型:SPI 工作電源電壓:3.15 V to 3.45 V 工作電源電流: 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:WLCSP-20
ISP1160BM/01,151 功能描述:USB 接口集成電路 DO NOT USE ORDER -T OR NO "-" RoHS:否 制造商:Cypress Semiconductor 產品:USB 2.0 數據速率: 接口類型:SPI 工作電源電壓:3.15 V to 3.45 V 工作電源電流: 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:WLCSP-20
ISP1160BM/01,157 功能描述:USB 接口集成電路 USB FULL SPEED HOST RoHS:否 制造商:Cypress Semiconductor 產品:USB 2.0 數據速率: 接口類型:SPI 工作電源電壓:3.15 V to 3.45 V 工作電源電流: 最大工作溫度:+ 85 C 安裝風格:SMD/SMT 封裝 / 箱體:WLCSP-20
