Philips Semiconductors
ISP1183
Low-power USB interface device with DMA
Product data
Rev. 01 — 24 February 2004
41 of 62
9397 750 11804
Koninklijke Philips Electronics N.V. 2004. All rights reserved.
13.4.4
Chip ID register (R: B5H)
This command reads the chip identification code and hardware version number. The
firmware must check this information to determine the supported functions and
features. This command accesses the Chip ID register, which is shown in
Table 44
.
Code (hex): B5 —
read chip ID
Transaction —
read 2 bytes
13.4.5
Interrupt register (R: C0H)
This command indicates the sources of interrupts as stored in the 4-byte Interrupt
register. Each individual endpoint has its own interrupt bit. The bit allocation of the
Interrupt register is shown in
Table 46
. Bit BUSTATUS verifies the current bus status
in the interrupt service routine. Interrupts are enabled through the Interrupt Enable
register, see
Section 13.1.5
.
While reading the interrupt register, read all the 4 bytes completely.
Code (hex): C0 —
read Interrupt register
Transaction —
read 4 bytes
Table 42:
Bit
15 to 11
10 to 8
7 to 0
Frame Number register: bit description
Symbol
Description
-
reserved
SOFRH[2:0]
SOF frame number (upper byte)
SOFRL[7:0]
SOF frame number (lower byte)
Table 43:
A0
HIGH
LOW
LOW
Example of Frame Number register access
Phase
Bus lines
command
D[7:0]
data
D[7:0]
data
D[7:0]
Byte #
-
0
1
Description
command code (B4H)
frame number (lower byte)
frame number (upper byte)
Table 44:
Bit
Symbol
Reset
Access
Bit
Symbol
Reset
Access
Chip ID register: bit allocation
15
14
13
12
11
10
9
8
CHIPIDH[7:0]
82H
R
4
CHIPIDL[7:0]
11H
R
R
7
R
6
R
5
R
3
R
2
R
1
R
0
R
R
R
R
R
R
R
Table 45:
Bit
15 to 8
7 to 0
Chip ID register: bit description
Symbol
CHIPIDH[7:0]
CHIPIDL[7:0]
Description
chip ID code (82H)
silicon version (11H)
