參數資料
型號： KSZ8695P
廠商： Micrel Inc
文件頁數： 3/42頁
文件大?。?/td> 0K
描述： IC ARM9 W/MMU PHY 10/100 289PBGA
標準包裝： 84
系列： *
類型： *
應用： *
安裝類型： 表面貼裝
封裝/外殼： 289-PBGA
供應商設備封裝： 289-PBGA（19x19）
包裝： 管件
配用： 576-1623-ND - BOARD EVALUATION KSZ8695P-MMB
其它名稱： 576-1509-5
KSZ8695P-ND
Micrel, Inc.
KS8695P
May 2006
11
M9999-051806
Pin Number
Pin Name
Type
(1)
Pin Function
P15
RCSN0
O
ROM/SRAM/FLASH Chip Select. Active Low.
R15
RCSN1
O
ROM/SRAM/FLASH Chip Select. Active Low.
B4
REQ1N
I
PCI Bus Request 1. Active Low. Input for Host Bridge Mode and Guest
Bridge Mode.
B3
REQ2N
I
PCI Bus Request 2. Active Low. Input for Host Bridge Mode, Not Used in
Guest Bridge Mode.
B2
REQ3N
I
PCI Bus Request 3. Active Low. Input for Host Bridge Mode, Not Used in
Guest Mode
A17
RESETN
I
KS8695P Chip Reset. Active Low.
T5
SDCASN
O
SDRAM Column Address Strobe. Active Low.
P5
SDCSN0
O
SDRAM Chip Select. Active Low Chip Select Pins for SDRAM.
R4
SDCSN1
O
SDRAM Chip Select. Active Low Chip Select Pins for SDRAM.
T7
SDICLK
I
SDRAM Clock In.
U7
SDOCLK
O
System/SDRAM Clock Out.
U6
SDQM0
O
SDRAM Data Input/Output Mask.
T6
SDQM1
O
SDRAM Data Input/Output Mask.
R6
SDQM2
O
SDRAM Data Input/Output Mask.
P6
SDQM3
O
SDRAM Data Input/Output Mask.
R5
SDRASN
O
SDRAM Row Address Strobe. Active Low.
U5
SDWEN
O
SDRAM Write Enable. Active Low.
A10
SERRN
O
PCI System Error Signal. Active Low.
D11
STOPN
I/O
PCI Stop Signal. Active Low.
G14
TCK
I
JTAG Test Clock.
F14
TDI
I
JTAG Test Data In.
F15
TDO
O
JTAG Test Data Out.
M4
TEST1
I
PHY Test Pin (factory reserved test signal).
F4
TEST2
I
PHY Test Pin (factory reserved test signal).
F17
TESTEN
I
Chip Test Enable (factory reserved test signal). Must be connected to GND
for normal operation.
G15
TMS
I
JTAG Test Mode Select.
C10
TRDYN
I/O
PCI Target Ready Signal. Active Low.
F16
TRSTN
I
JTAG Test Reset. Active Low.
M14
UCTSN/
BISTEN
I
UART Data Set Ready. Active Low. BIST Enable (factory reserved test
signal).
L15
UDCDN/
SCANEN
I
UART Data Carrier Detect. Scan Enable (factory reserved test signal).
M16
UDSRN
I
UART Data Set Ready. Active Low.
N15
UDTRN/
DBGENN
O/I
UART Data Terminal Ready. Active Low. Debug Enable (factory reserved
test signal).
L14
URIN/TSTRST
I
UART Ring Indicator/Chip Test Reset (factory reserved test signal).
M15
URTSN/
CPUCLKSEL
O/I
UART Request to Send/CPU Clock Select.
Note
:
1. I = Input.
O = Output.
I/O = Bidirectional.
O/I = Output in normal mode; input pin during reset.
