參數資料
型號： MAX9393ETJ
廠商： MAXIM INTEGRATED PRODUCTS INC
元件分類： 運動控制電子
英文描述： Anything-to-LVDS Dual 2 x 2 Crosspoint Switches
中文描述： DUAL 2-CHANNEL, CROSS POINT SWITCH, QCC32
封裝： 5 X 5 MM, 0.80 MM HEIGHT, TQFN-32
文件頁數： 2/14頁
文件大?。?/td> 309K
代理商： MAX9393ETJ
M
Anything-to-LVDS Dual 2 x 2
Crosspoint Switches
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
V
CC
to GND...........................................................-0.3V to +4.1V
IN_ _,
IN_ _
, OUT_ _,
OUT_ _
, EN_ _,
_SEL_ to GND..........................................-0.3V to (V
CC
+ 0.3V)
IN_ _ to
IN_ _
..........................................................................
±
3V
Short-Circuit Duration (OUT_ _,
OUT_ _
) ...................Continuous
Continuous Power Dissipation (T
A
= +70
°
C)
32-Pin TQFP (derate 13.1mW/
°
C
above +70
°
C).............................................................1047mW
32-Pin 5mm x 5mm Thin QFN (derate 21.3mW/
°
C
above +70
°
C).............................................................1702mW
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +3.0V to +3.6V, R
L
= 100
±
1%, EN_ _ = V
CC
, V
CM
= 0.05V to (V
CC
- 0.6V) (MAX9392), V
CM
= 0.6V to (V
CC
- 0.05V)
(MAX9393), T
A
= -40
°
C to +85
°
C, unless otherwise noted. Typical values are at V
CC
= +3.3V, |V
ID
| = 0.2V, V
CM
= +1.2V, T
A
= +25
°
C,
unless otherwise noted.) (Notes 1, 2, and 3)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Junction-to-Ambient Thermal Resistance in Still Air
32-Pin TQFP............................................................+76.4
°
C/W
32-Pin 5mm x 5mm Thin QFN....................................+47
°
C/W
Junction-to-Case Thermal Resistance
32-Pin 5mm x 5mm Thin QFN......................................+2
°
C/W
Operating Temperature Range ...........................-40
°
C to +85
°
C
Junction Temperature......................................................+150
°
C
Storage Temperature Range.............................-65
°
C to +150
°
C
Soldering Temperature (10s)...........................................+300
°
C
PARAMETER
SYM B O L
CONDITIONS
MIN
TYP
MAX
UNITS
LVCMOS/LVTTL INPUTS (EN_ _, _SEL_)
Input High Voltage
Input Low Voltage
Input High Current
Input Low Current
DIFFERENTIAL INPUTS (IN_ _,
IN_ _
)
Differential Input Voltage
V
IH
V
IL
I
IH
I
IL
2.0
0
0
0
V
CC
0.8
20
10
V
V
μA
μA
V
IN
= +2.0V to V
CC
V
IN
= 0 to +0.8V
V
ID
V
ILD
0 and V
IHD
V
CC
, Figure 1
MAX9392
MAX9393
MAX9392
|V
ID
| 3.0V
MAX9393
|V
ID
| 3.0V
0.1
0.05
0.6
-50
-10
3.0
V
V
CC
- 0.6
V
CC
- 0.05
+10
+90
Input Common-Mode Range
V
CM
V
Input Current
I
IN_ _
,
I
IN_ _
μA
LVDS OUTPUTS (OUT_ _,
OUT_ _
)
Differential Output Voltage
V
OD
R
L
= 100
, Figure 2
250
350
450
mV
Change in Magnitude of V
OD
Between Complementary Output
States
V
OD
Figure 2
1.0
50
mV
Offset Common-Mode Voltage
V
OS
Figure 2
1.125
1.25
1.375
V
Change in Magnitude of V
OS
Between Complementary Output
States
V
OS
Figure 2
1.0
50
mV
