1
DS06-80101-1E
FUJITSU SEMICONDUCTOR
DATA SHEET
ASSP
IF Band
PLL Frequency Synthesizer
MB15S00 Series
I
DESCRIPTION
The Fujitsu MB15S series is an exclusive Intermediate Frequency (IF) band Phase Locked Loop (PLL) frequency synthesizer
with pulse swallow operation. It can operate maximum at 300MHz.
The reference divider and comparison divider have fixed divide ratios, so that it is not required to set the divide ratios by a
μ
controller externally. Because the dividers are designed by means of
SOP and
SSOP 8-pin
plastic packages are available.
MASK ROM
method, a customer can chose them optionally.
All of the above features help a system designer for
easier
as well as
compact
layout work.
It operates with a supply voltage of 3.0V typ. and dissipates 3.5 mA typ. of current realized through the use of Fujitsu’s Bi-CMOS
technology.
I
FEATURES
Operating frequency : 300MHz max.
Low power supply current: I
Pulse swallow function;
300MHz Prescaler: 16/17 or 32/33
MASK ROM optional the comparison and reference dividers:
- Main counter ; 5 to 4,095
- Swallow counter ; 0 to 31
- Reference counter ; 5 to 4,095
Charge pump options:
- Analog cellular phones ; Low sensitivity charge pump for direct modulation.
- Digital cellular phones ; Super charger circuit for High speed tuning.
Low power supply voltage: V
CC
= 2.7 to 3.6V
Wide operating temperature: Ta = –40 to 85
Plastic 8-pin SOP and 8-pin SSOP packages
CC
(total) = 3.5 mA typ. (Vcc = 3V)
°
C
I
PACKAGES
(FPT-8P-M03)
(FPT-8P-M01)
8-pin, Plastic SOP
8-pin, Plastic SSOP
