MB91270/280 Series
7
■ PIN FUNCTION
* : See “■ I/O CIRCUIT TYPE” for the I/O circuit type.
(Continued)
Pin No.
Pin name
Function
name
I/O circuit
type*
Function
90
X1
OB
Oscillator output pin
91
X0
OA
Oscillator input pin
52
INITX
N
Reset input pin (“L” active)
49 to 51
MD2 to MD0 MD2 to MD0
J
Operation mode select input pin.
Connect to VCC or VSS directly.
Port 0
75
P00/AD00/
SIN5/INT8
P00
T
General-purpose I/O ports.
This function is enabled in single-chip mode.
AD00
External address/data bus I/O pin bit 0
This function is enabled when the external bus is enabled.
INT8
External interrupt request 8 input pin
SIN5
Serial data input pin for LIN-UART5
76
P01/AD01/
SOT5/INT9
P01
T
General-purpose I/O ports.
This function is enabled in single-chip mode.
AD01
External address/data bus I/O pin bit 1
This function is enabled when the external bus is enabled.
INT9
External interrupt request 9 input pin
SOT5
Serial data output pin for LIN-UART5
77
P02/AD02/
SCK5/INT10
P02
T
General-purpose I/O ports.
This function is enabled in single-chip mode.
AD02
External address/data bus I/O pin bit 2
This function is enabled when the external bus is enabled.
INT10
External interrupt request 10 input pin
SCK5
Clock I/O pin for LIN-UART5
78
P03/AD03/
SIN6/INT11
P03
T
General-purpose I/O ports.
This function is enabled in single-chip mode.
AD03
External address/data bus I/O pin bit 3
This function is enabled when the external bus is enabled.
INT11
External interrupt request 11 input pin
SIN6
Serial data input pin for LIN-UART6
79
P04/AD04/
SOT6/INT12
P04
T
General-purpose I/O ports.
This function is enabled in single-chip mode.
AD04
External address/data bus I/O pin bit 4
This function is enabled when the external bus is enabled.
INT12
External interrupt request 12 input pin
SOT6
Serial data output pin for LIN-UART6
