MCP2510
DS21291C-page 26
Preliminary
1999 Microchip Technology Inc.
REGISTER 4-3:
BFPCTRL - RXNBF Pin Control and Status Register (ADDRESS: 0Ch)
REGISTER 4-4:
RXBNSIDH - Receive Buffer N Standard Identifier High (ADDRESS: 61h, 71h)
U-0
R/W-0
—
B1BFS
B0BFS
B1BFE
B0BFE
B1BFM
B0BFM
R = Readable bit
W = Writable bit
C = Bit can be cleared by
MCU but not set
U = Unimplemented -
reads as ‘0’
- n = Value at POR reset
bit 7
bit 0
bit 7:
Unimplemented: Reads as ‘0’
bit 6:
Unimplemented: Reads as ‘0’
bit 5:
B1BFS: RX1BF Pin State (digital output mode only)
Reads as 0 when RX1BF is configured as interrupt pin
bit 4:
B0BFS: RX0BF Pin State (digital output mode only)
Reads as 0 when RX0BF is configured as interrupt pin
bit 3:
B1BFE: RX1BF Pin Function Enable
1 = Pin function enabled, operation mode determined by B1BFM bit
0 = Pin function disabled, pin goes to high impedance state
bit 2:
B0BFE: RX0BF Pin Function Enable
1 = Pin function enabled, operation mode determined by B0BFM bit
0 = Pin Function disabled, pin goes to high impedance state
bit 1:
B1BFM: RX1BF Pin Operation Mode
1 = Pin is used as interrupt when valid message loaded into RXB1
0 = Digital output mode
bit 0:
B0BFM: RX0BF Pin Operation Mode
1 = Pin is used as interrupt when valid message loaded into RXB0
0 = Digital output mode
R-x
SID10
SID9
SID8
SID7
SID6
SID5
SID4
SID3
R = Readable bit
W = Writable bit
C = Bit can be cleared by
MCU but not set
U = Unimplemented -
reads as ‘0’
- n = Value at POR reset
bit 7
bit 0
bit 7-0:
SID<10:3>: Standard Identifier Bits <10:3>
These bits contain the eight most significant bits of the Standard Identifier for the received message
