Semiconductor
MSM5416273
1/40
262,144-Word
￥
16-Bit Multiport DRAM
DESCRIPTION
The MSM5416273 is a 4-Mbit CMOS multiport DRAM composed of a 262,144-word by 16-bit
dynamic RAM, and a 512-word by 16-bit SAM. Its RAM and SAM operate independently and
asynchronously.
It supports three types of operations: random access to RAM port, high speed serial access to
SAM port, and bidirectional transfer of data between any selected row in the RAM port and the
SAM port. In addition to the conventional multiport DRAM operating modes, the MSM5416273
features block write, flash write functions, extended page mode on the RAM port, a split data
transfer capability, and programmable stops on the SAM port. The SAM port requires no refresh
operation because it uses static CMOS flip-flops.
FEATURES
Single power supply: 5 V
±
10%
Full TTL compatibility
Multiport organization
RAM :256K word
￥
16 bits
SAM :512 word
￥
16 bits
Extended page mode
Write per bit
Persistent write per bit
Byte read/write
Masked flash write
Masked block write (8 columns
)
Package:
64-pin 525 mil plastic SSOP
(SSOP64-P-525-0.80-K)
(Product : MSM5416273-xxGS-K)
xx indicates speed rank.
PRODUCT FAMILY
RAS
only refresh
CAS
before
RAS
refresh
Hidden refresh
Serial read/write
512 tap location
Programmable stops
Bidirectional data transfer
Split transfer
Masked write transfer
Refresh: 512 cycles/8 ms
Access Time
RAM
50 ns
60 ns
70 ns
Cycle Time
RAM
110 ns
120 ns
140 ns
Power Dissipation
Operating
180 mA
170 mA
160 mA
Standby
8 mA
8 mA
8 mA
SAM
17 ns
18 ns
20 ns
SAM
20 ns
22 ns
22 ns
Family
MSM5416273-50
MSM5416273-60
MSM5416273-70
E2L0021-17-Y1
This version: Jan. 1998
Previous version: Dec. 1996
