Semiconductor
MSM7543/7544
4/19
PIN AND FUNCTIONAL DESCRIPTIONS
AIN+, AIN–, GSX
Transmit analog input and transmit level adjustment.
AIN+ is a non-inverting input to the op-amp; AIN– is an inverting input to the op-amp; GSX is
connected to the output of the op-amp and is used to adjust the level, as shown below.
When not using AIN– and AIN+, connect AIN– to GSX and AIN+ to SG. During power saving
and power down modes, the GSX output is at AG voltage.
AG
Analog signal ground.
VFRO
Receive filter output.
The output signal has an amplitude of 2.4 V
PP
above and below the signal ground voltage (SG)
when the digital signal of +3 dBmO is input to PCMIN and can drive a load of 20 k
W
or more.
For driving a load of 20 k
W
or less, connect a resistor of 20 k
W
or more between the pins VFRO
and PWI.
When adding the frequency characteristics to the receive signal, refer to the application example.
During power saving or power down mode, the output of VFRO is at the voltage level of AG.
–
+
AIN–
AIN+
SG
C1
Analog input
1) Inverting input type
R1 : variable
R2 > 20 k
W
C1 > 1/(2
￥
3.14
￥
30
￥
R1)
Gain = R2/R1
￡
10
R2
GSX
+
–
AIN+
AIN–
GSX
2) Non inverting input type
R3 > 20 k
W
R4 > 20 k
W
R5 > 50 k
W
C2 > 1/ (2
￥
3.14
￥
30
￥
R5)
Gain = 1 + R4 / R3
￡
10
R4
SG
C2
Analog input
R3
R5
R1
