1/25
Semiconductor
MSM7557
GENERAL DESCRIPTION
The MSM7557 is a single chip MSK modem with base band voice processor for cordless telephone.
The MSM7557 voice transmit block consists of high pass filter, compressor, pre-emphasis, limiter
and splatter filter.
Voice receive block consists of Band pass filter, De-emphasis and Expander.
FEATURES
Available to transmit modem signal and also transmit base band voice signal through wireless
transmission path (0.3 kHz to 3.4 kHz)
Built-in compandor circuit
Upper limit of voice band (3306 Hz/3400 Hz/3500 Hz) is selectable
Modem bit rate (2400/1200 bps) is selectable
Transmit function and receive function operate separately
Emphasis mode selectable
Built-in bit synchronous detector and frame synchronous detector
Built-in limiter level generator and external limit voltage input
Dynamic range selectable
Built-in crystal oscillator circuit
Wide range power supply voltage (2.7V ~ 5.5V)
Package :
56-pin plastic QFP
(QFP56-P-910-0.65-2K)(Product name : MSM7557GS-2K)
Single Chip MSK Modem with Compandor for Cordless Telephone
E2A0046-16-X1
This version: Jan. 1998
Previous version: Nov. 1996
