參數資料
型號： MSP430F2274MRHAEP
廠商： TEXAS INSTRUMENTS INC
元件分類： 微控制器/微處理器
英文描述： 16-BIT, FLASH, RISC MICROCONTROLLER, PQCC40
封裝： GREEN, PLASTIC, MO-220VJJD-2, VQFN-40
文件頁數： 35/79頁
文件大小： 1274K
代理商： MSP430F2274MRHAEP
SLAS614C – SEPTEMBER 2008 – REVISED JULY 2010
www.ti.com
10-Bit ADC, Power-Supply and Input Range Conditions – Electrical Characteristics
(1)
over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted)
PARAMETER
TEST CONDITIONS
TA
VCC
MIN
TYP
MAX
UNIT
VCC
Analog supply voltage range
VSS = 0 V
–55°C to125 °C
2.2
3.6
V
All Ax terminals,
VAx
Analog input voltage range (2)
Analog inputs selected in
–55°C to 125°C
0
VCC
V
ADC10AE register
fADC10CLK = 5.0 MHz,
2.2 V
0.52
1.05
ADC10ON = 1, REFON = 0,
IADC10
ADC10 supply current(3)
ADC10SHT0 = 1,
–55°C to 125°C
mA
3 V
0.6
1.2
ADC10SHT1 = 0,
ADC10DIV = 0
fADC10CLK = 5.0 MHz,
ADC10ON = 0, REF2_5V = 0,
–55°C to 125°C
2.2 V/3 V
REFON = 1, REFOUT = 0
Reference supply current,
IREF+
0.25
.4
mA
reference buffer disabled(4)
fADC10CLK = 5.0 MHz,
ADC10ON = 0, REF2_5V = 1,
–55°C to 125°C
3 V
REFON = 1, REFOUT = 0
fADC10CLK = 5.0 MHz,
–55°C to 85°C
2.2 V/3 V
1.1
1.4
Reference buffer supply current
ADC10ON = 0, REFON = 1,
IREFB,0
mA
with ADC10SR = 0(4)
REF2_5V = 0,
125°C
2.2 V/3 V
1.8
REFOUT = 1, ADC10SR = 0
fADC10CLK = 5.0 MHz,
–55°C to 85°C
2.2 V/3 V
0.5
.7
mA
Reference buffer supply current
ADC10ON = 0, REFON = 1,
IREFB,1
with ADC10SR = 1(4)
REF2_5V = 0, REFOUT = 1,
125°C
2.2 V/3 V
.8
mA
ADC10SR=1
Only one terminal Ax selected at
CI
Input capacitance
27
pF
a time
RI
Input MUX ON resistance
0 V
≤ VAx ≤ VCC
2.2 V/3 V
2000
(1)
The leakage current is defined in the leakage current table with Px.x/Ax parameter.
(2)
The analog input voltage range must be within the selected reference voltage range VR+ to VR– for valid conversion results.
(3)
The internal reference supply current is not included in current consumption parameter IADC10.
(4)
The internal reference current is supplied via terminal VCC. Consumption is independent of the ADC10ON control bit, unless a
conversion is active. The REFON bit enables the built-in reference to settle before starting an A/D conversion.
40
Copyright 2008–2010, Texas Instruments Incorporated
Product Folder Link(s): MSP430F2274-EP
相關PDF資料
PDF描述
MSP430F2619SKGD1 16-BIT, FLASH, 16 MHz, RISC MICROCONTROLLER, UUC82
MSP430F423IPMR 16-BIT, FLASH, 8 MHz, RISC MICROCONTROLLER, PQFP64
MSP430F5326IRGC RISC MICROCONTROLLER, PQCC64
MSP430P325IPG 16-BIT, OTPROM, 3.3 MHz, RISC MICROCONTROLLER, PQFP64
MSP430P337AIPJM 16-BIT, OTPROM, 3.8 MHz, RISC MICROCONTROLLER, PQFP100
相關代理商/技術參數
參數描述
MSP430F2274MRHATEP 功能描述:16位微控制器 - MCU MicroLogic-MCU 16B MCU RoHS:否 制造商:Texas Instruments 核心:RISC 處理器系列:MSP430FR572x 數據總線寬度:16 bit 最大時鐘頻率:24 MHz 程序存儲器大小:8 KB 數據 RAM 大小:1 KB 片上 ADC:Yes 工作電源電壓:2 V to 3.6 V 工作溫度范圍:- 40 C to + 85 C 封裝 / 箱體:VQFN-40 安裝風格:SMD/SMT
MSP430F2274TDA 功能描述:16位微控制器 - MCU 16-bit Ultra-Lo-Pwr Microcontroller RoHS:否 制造商:Texas Instruments 核心:RISC 處理器系列:MSP430FR572x 數據總線寬度:16 bit 最大時鐘頻率:24 MHz 程序存儲器大小:8 KB 數據 RAM 大小:1 KB 片上 ADC:Yes 工作電源電壓:2 V to 3.6 V 工作溫度范圍:- 40 C to + 85 C 封裝 / 箱體:VQFN-40 安裝風格:SMD/SMT
MSP430F2274TDAQ1 制造商:TI 制造商全稱:Texas Instruments 功能描述:MIXED SIGNAL MICROCONTROLLER
MSP430F2274TDAR 功能描述:16位微控制器 - MCU 16-bit Ultra-Lo-Pwr Microcontroller RoHS:否 制造商:Texas Instruments 核心:RISC 處理器系列:MSP430FR572x 數據總線寬度:16 bit 最大時鐘頻率:24 MHz 程序存儲器大小:8 KB 數據 RAM 大小:1 KB 片上 ADC:Yes 工作電源電壓:2 V to 3.6 V 工作溫度范圍:- 40 C to + 85 C 封裝 / 箱體:VQFN-40 安裝風格:SMD/SMT
MSP430F2274TRHA 制造商:TI 制造商全稱:Texas Instruments 功能描述:MIXED SIGNAL MICROCONTROLLER
