參數資料
| 型號： | NCS2202SN1T1 |
| 廠商： | ON SEMICONDUCTOR |
| 元件分類： | 比較器 |
| 英文描述： | Low Voltage Comparators |
| 中文描述： | COMPARATOR, 8000 uV OFFSET-MAX, 1100 ns RESPONSE TIME, PDSO5 |
| 封裝： | PLASTIC, SC-59, SOT-23, TSOP-5 |
| 文件頁數： | 1/18頁 |
| 文件大小： | 152K |
| 代理商： | NCS2202SN1T1 |
Semiconductor Components Industries, LLC, 2005
March, 2005
Rev. 6
1
Publication Order Number:
NCS2200/D
NCS2200 Series
Low Voltage Comparators
The NCS2200 Series is an industry first sub
one volt, low power
comparator family. These devices consume only 10 A of supply
current. They are guaranteed to operate at a low voltage of 0.85 V
which allows them to be used in systems that require less than 1.0 V
and are fully operational up to 6.0 V which makes them convenient for
use in both 3.0 V and 5.0 V systems. Additional features include no
output phase inversion with overdriven inputs, internal hysteresis,
which allows for clean output switching, and rail
to
rail input and
output performance. The NCS2200 Series is available in the tiny
SOT
23
5 and SOT
23
6 package. There are eight options featuring
two industry standard pinouts. Additionally, the NCS2200 device is
available in the tiny QFN 2x2.2 package and the SC70
5 package.
(Table 1)
The NCS2201/3 Series in the SOT
23
6 package features an enable
function, which can be externally controlled. When the enable pin is
pulled low (output tri
state mode), current consumption is typically
0.3 A. This allows the user to implement these devices in power
sensitive applications such as portable electronics.
Features
Operating Voltage of 0.85 V to 6.0 V
Rail
to
Rail Input/Output Performance
Low Supply Current of 10 A
No Phase Inversion with Overdriven Input Signals
Glitchless Transitioning in or out of Tri
State Mode
Complementary or Open Drain Output Configuration
Available with the Enable Function
Internal Hysteresis
Propagation Delay of 1.1 s
Pb
Free Packages are Available
Typical Applications
Single Cell NiCd/NiMH Battery Powered Applications
Cellular Telephones
Alarm and Security Systems
Personal Digital Assistants
QFN 2x2.2
SQL SUFFIX
CASE 488
SOT
23
5
SN SUFFIX
CASE 483
See detailed ordering and shipping information in the package
dimensions section on page 12 of this data sheet.
ORDERING INFORMATION
SOT
23
6
SN SUFFIX
CASE 318G
See general marking information in the device marking
section on page 13 of this data sheet.
DEVICE MARKING INFORMATION
http://onsemi.com
SC70
5
SQ SUFFIX
CASE 419A
5
1
6
1
1
6
5
1
