www.ti.com
ABSOLUTE MAXIMUM RATINGS
over operating free-air temperature range unless otherwise noted
all voltages with respect to GND
(1)
RECOMMENDED OPERATING CONDITIONS
PACKAGE SPECIFICATIONS
PTN78060A
SLTS245A–APRIL 2005–REVISED MAY 2005
These devices have limited built-in ESD protection. The leads should be shorted together or the device
placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
ORDERING INFORMATION
PTN78060 (Basic Model)
Output Voltage
Part Number
PTN78060AAH
PTN78060AAS
(1)(2)
PTN78060AAZ
(1)(3)
Description
Horizontal T/H (Pb-free)
Horizontal SMD (standard)
Horizontal SMD (Pb-free)
Package Designator
EUW-7
EUY-7
EUY-7
–15 V to –3 V
(1)
(2)
(3)
Add a T suffix for tape and reel option on SMD packages.
Standard option
specifies Sn/Pb solder ball material.
Lead (Pb) - free option
specifies Sn/Ag solder ball material.
UNIT
T
A
Operating free-air temperature
Solder reflow temperature
Over V
I
range
Surface temperature of module body or
pins
–40°C to 85°C
235°C
260
°
C
–40°C to 125°C
15 W
Horizontal SMD (suffix AS)
Horizontal SMD (suffix AZ)
T
stg
P
O
Storage temperature
Output power
|V
O
|
≥
5 V
(1)
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
MIN
MAX
UNIT
V
°C
V
I
T
A
Input voltage
Operating free-air temperature
9
32 - |V
O
|
–40
85
PTN78060x (Suffix AH, AS, and AZ)
Weight
Flammability
3.9 grams
Meets UL 94 V-O
Per Mil-STD-883D, Method 2002.3, 1 ms, sine,
mounted
Mechanical shock
500 Gs
(1)
Horizontal T/H (suffix AH)
Horizontal SMD (suffix AS & AZ)
20 Gs
(1)
20 Gs
(1)
Mechanical vibration
Mil-STD-883D, Method 2007.2, 20-2000 Hz
(1)
Qualification limit.
2
