SGUS014H FEBRUARY 1991 REVISED JUNE 2004
8
POST OFFICE BOX 1443
HOUSTON, TEXAS 772511443
Pin Functions (Continued)
PIN
TYPE
DESCRIPTION
CONDITIONS
WHEN
SIGNAL IS Z TYPE§
NAME
QTY
SERIAL PORT 0 SIGNALS
CLKX0
1
I/O/Z
Serial port 0 transmit clock. CLKX0 is the serial-shift clock for the serial port 0
transmitter.
S
R
DX0
1
I/O/Z
Data transmit output. Serial port 0 transmits serial data on DX0.
S
R
FSX0
1
I/O/Z
Frame synchronization pulse for transmit. The FSX0 pulse initiates the transmit-data
process over DX0.
S
R
CLKR0
1
I/O/Z
Serial port 0 receive clock. CLKR0 is the serial-shift clock for the serial port 0 receiver.
S
R
DR0
1
I/O/Z
Data receive. Serial port 0 receives serial data on DR0.
S
R
FSR0
1
I/O/Z
Frame synchronization pulse for receive. The FSR0 pulse initiates the receive-data
process over DR0.
S
R
SERIAL PORT 1 SIGNALS
CLKX1
1
I/O/Z
Serial port 1 transmit clock. CLKX1 is the serial-shift clock for the serial port 1
transmitter.
S
R
DX1
1
I/O/Z
Data transmit output. Serial port 1 transmits serial data on DX1.
S
R
FSX1
1
I/O/Z
Frame synchronization pulse for transmit. The FSX1 pulse initiates the transmit-data
process over DX1.
S
R
CLKR1
1
I/O/Z
Serial port 1 receive clock. CLKR1 is the serial-shift clock for the serial port 1 receiver.
S
R
DR1
1
I/O/Z
Data receive. Serial port 1 receives serial data on DR1.
S
R
FSR1
1
I/O/Z
Frame synchronization pulse for receive. The FSR1 pulse initiates the receive-data
process over DR1.
S
R
TIMER 0 SIGNALS
TCLK0
1
I/O/Z
Timer clock 0. As an input, TCLK0 is used by timer 0 to count external pulses. As an
output, TCLK0 outputs pulses generated by timer 0.
S
R
TIMER 1 SIGNALS
TCLK1
1
I/O/Z
Timer clock 1. As an input, TCLK1 is used by timer 1 to count external pulses. As an
output, TCLK1 outputs pulses generated by timer 1.
S
R
SUPPLY AND OSCILLATOR SIGNALS (see Note 1)
5-V supply
5-V supply
5-V supply
5-V supply
5-V supply
5-V supply
VDD
IODVDD
ADVDD
PDVDD
DDVDD
MDVDD
VSS
DVSS
CVSS
I = input, O = output, Z = high-impedance state, NC = no connect
For GB package
§S = SHZ active, H = HOLD active, R = RESET active
Recommended decoupling capacitor is 0.1
μ
F.
NOTE 1: CVSS, VSS, and IVSS are on the same plane.
4
I
2
I
2
I
1
I
2
I
1
I
4
I
Ground
4
I
Ground
2
I
Ground
