3
Precision Edge
SY58017U
Micrel, Inc.
M9999-082807
hbwhelp@micrel.com or (408) 955-1690
Absolute Maximum Ratings(1)
Power Supply Voltage (VCC ) ...................... –0.5V to +4.0V
Input Voltage (VIN) ......................................... –0.5V to VCC
CML Output Voltage (VOUT) ......... VCC –1.0V to VCC +0.5V
Termination Current(3)
Source or sink current on VT pin ........................ ±100mA
Input Current
Source or sink current on IN, /IN pin .................... ±50mA
Lead Temperature (soldering, 20 sec.) ..................... 260°C
Storage Temperature Range (TS ) ........... –65°C to +150°C
Operating Ratings(2)
Power Supply Voltage (VCC) ............... +2.375V to +2.625V
............................................................ +3.0V to +3.6V
Ambient Temperature Range (TA) ............. –40°C to +85°C
Package Thermal Resistance(4)
MLF (θJA)
Still-Air ............................................................. 60°C/W
MLF (ψJB)
Junction-to-Board ............................................ 38°C/W
TA = –40°C to 85°C, unless otherwise stated.
Symbol
Parameter
Condition
Min
Typ
Max
Units
VCC
Power Supply Voltage
VCC = 2.5V
2.375
2.5
2.625
V
VCC = 3.3V
3.0
3.3
3.6
V
ICC
Power Supply Current
No load, max. VCC
(6)
55
70
mA
RDIFF_IN
Differential Input Resistance
80
100
120
(IN0-to-/IN0, IN1-to-/IN1)
RIN
Input Resistance
40
50
60
(IN0-to-VT0, /IN0-to-VT0,
IN1-to-VT1, /IN1-to-VT1)
VIH
Input HIGH Voltage
Note 7
VCC–1.6
VCC
V
(IN0, /IN0, IN1, /IN1)
VIL
Input LOW Voltage
0
VIH–0.1
V
(IN0, /IN0, IN1, /IN1)
VIN
Input Voltage Swing
See Figure 1a
0.1
1.7
V
(IN0, /IN0, IN1, /IN1)
VDIFF_IN
Differential Input Voltage Swing
See Figure 1b
0.2
V
|IN0, /IN0|, |IN1, /IN1|
VT IN
IN to VT
1.28
V
(IN0, /IN0, IN1, /IN1)
Notes:
1. Permanent device damage may occur if
“Absolute Maximum Ratings” are exceeded. This is a stress rating only and functional operation is not
implied at conditions other than those detailed in the operational sections of this data sheet. Exposure to
“Absolute Maximum Ratings” conditions for
extended periods may affect device reliability.
2. The data sheet limits are not guaranteed if the device is operated beyond the operating ratings.
3. Due to the limited drive capability, use for input of the same package only.
4. Package thermal resistance assumes exposed pad is soldered (or equivalent) to the device’s most negative potential (GND) on the PCB. ψJB uses
4-layer θJA in still-air measurment, unless otherwise stated.
5. The circuit is designed to meet the DC specifications shown in the above table after thermal equilibrium has been established.
6. Includes current through internal 50 pull-ups.
7. VIH (min) not lower than 1.2V.
DC ELECTRICAL CHARACTERISTICS(5)
