TA1383AFG
2005-09-05
3
Pins
(unless otherwise specified, V
CC1
=
9 V, V
CC2
=
5 V, Ta
=
25°C)
Pin
No.
Symbol
Function
Interface
I/O Signal
1
V
CC1
(9 V)
V
for sync separation block,
outputs, and interface. Connects 9 V
(typ.).
2
4
Y1/SYNC1 IN
Y2/SYNC2 IN
Y signal input pin.
Inputs NTSC (525I) signal via clamp
capacitor.
Sync signal is separated from Y signal
input to this pin.
Can also be used for sync-only input
pins.
When not used, leave open.
1 V
p-p
(with Sync)
Sync-Tip: 2.0 V
3
SYNC OUT
Outputs sync-separated C-SYNC.
Open collector output.
High/Low
5
VD IN
Inputs vertical sync VD signal.
Inputs positive- and negative-polarity
signals.
When not used, leave open.
or
6
D-SYNC2 IN
(for freq. det.)
Inputs Y signal for identifying
frequency.
Inputs Y signals such as 525IP, 720P,
and 1125I via clamp capacitor.
When not used, leave open.
1 V
p-p
(with Sync)
Sync-Tip: 2.0 V
or
7
HD IN
Inputs horizontal sync HD signal.
Inputs positive- and negative-polarity
signals.
When not used, leave open.
or
1
3
11
100
1
5
11
1 k
4
2
μ
A
1
1
6
1
11
1 k
1
1
7
11
500
5
Th: 0.7 V
Th: 0.7 V
Th: 0.7 V
Th: 0.7 V
1
1
11
1 k
1
2
1 k
1 k
2
4
5
μ
A
9
3
