TLP2601
2002-09-25
1
TOSHIBA Photocoupler GaA
As Ired & Photo
IC
TLP2601
Isolated Line Receiver
Simplex / Multiplex Data Transmission
Computer
Peripheral Interface
Microprocessor System Interface
Digital Isolation For A/D, D/A Conversion
Direct Replacement For HCPL
2601
The TOSHIBA TLP2601 a photocoupler which combines a GaA
As IRed
as the emitter and an integrated high gain, high speed photodetector.
The output of the detector circuit is an open collector, Schottky clamped
transistor.
A Faraday shield integrated on the photodetector chip reduces the effects
of capacitive coupling between the input LED emitter and the high gain
stages of the detector. This provides an effective common mode transient
immunity of 1000V/μs.
Input current thresholds: I
F
= 5mA max.
Isolation voltage: 2500Vrms min.
Switching speed: 10MBd
Common mode transient immunity: 1000V/μs min.
Guaranteed performance over temp.: 0°C~70°C
UL Recognized: UL1577, file No. E67349
Truth Table
(positive logic)
Input
Enable
Output
H
H
L
L
H
H
H
L
H
L
L
H
A 0.01 to 0.1μF bypass capacitor must be
connected between pins 8 and 5 (see Note 1).
Pin Configuration
(top view)
1
2
3
4
8
7
6
5
SHIELD
Schematic
I
F
V
F
2
3
SHIELD
V
CC
V
O
V
E
GND
8
7
6
5
I
CC
I
O
I
E
+
-
TOSHIBA
Weight: 0.54g
11
10C4
Unit in mm
