TMS320VC5409
FIXED-POINT DIGITAL SIGNAL PROCESSOR
SPRS082C – APRIL 1999 – REVISED MARCH 2000
10
POST OFFICE BOX 1443
HOUSTON, TEXAS 77251–1443
Terminal Functions (Continued)
NAME
DESCRIPTION
I/O
INTERNAL
PIN STATE
TERMINAL
HOST-PORT INTERFACE SIGNALS (CONTINUED)
HR/W
Pullup
resistor
I
Read/write. HR/W controls the direction of an HPI transfer. R/W has an internal pullup resistor that
is only enabled when HPIENA = 0.
HRDY
O/Z
Ready. The ready output informs the host when the HPI is ready for the next transfer. HRDY goes
into the high-impedance state when OFF is low.
Interrupt. This output is used to interrupt the host. When the DSP is in reset, HINT is driven high
.
The signal goes into the high-impedance state when OFF is low.
HINT
O/Z
HPIENA
Pulldown
resistor
I
HPI module select. HPIENA must be driven high during reset to enable the HPI. An internal
pulldown resistor is always active and the HPIENA pin is sampled on the rising edge of RS. If
HPIENA is left open or is driven low during reset, the HPI module is disabled. Once the HPI is
disabled, the HPIENA pin has no effect until the ’5409 is reset.
HPI16
Pulldown
resistor
I
HPI 16-bit select pin (internal pulldown, default HPI8). HPI16 = 1 selects the non-multiplexed mode.
The non-multiplexed mode allows hosts with separate address/data buses to access the HPI
address range via the 16 address pins (A15–A0). 16-bit data is also accessible through pins D0
through D15. Host-to-DSP and DSP-to-Host interrupts are not supported. There are no HPIC and
HPIA register accesses in the non-multiplexed mode.
The HPI16 pin is sampled at RESET. The user should never change the value of the HPI16 pin while
the RESET signal is HIGH.
SUPPLY PINS
CVDD
DVDD
VSS
S
+VDD. Dedicated 1.8-V power supply for the core CPU
+VDD. Dedicated 3.3-V power supply for the I/O pins
Ground
S
S
TEST PINS
TCK
Schmitt
trigger/pullup
resistor
I
IEEE standard 1149.1 test clock. TCK is normally a free-running clock signal with a 50% duty cycle.
The changes on the test access port (TAP) of input signals TMS and TDI are clocked into the TAP
controller, instruction register, or selected test data register on the rising edge of TCK. Changes at
the TAP output signal (TDO) occur on the falling edge of TCK.
TDI
Pullup
resistor
I
IEEE standard 1149.1 test data input pin with internal pullup device. TDI is clocked into the selected
register (instruction or data) on a rising edge of TCK.
TDO
O/Z
IEEE standard 1149.1 test data output. The contents of the selected register (instruction or data)
are shifted out of TDO on the falling edge of TCK. TDO is in the high-impedance state except when
the scanning of data is in progress. TDO also goes into the high-impedance state when OFF is low.
TMS
Pullup
resistor
I
IEEE standard 1149.1 test mode select. Pin with internal pullup device. This serial control input is
clocked into the TAP controller on the rising edge of TCK.
TRST
Pulldown
resistor
I
IEEE standard 1149.1 test reset. TRST, when high, gives the IEEE standard 1149.1 scan system
control of the operations of the device. If TRST is not connected or is driven low, the device operates
in its functional mode, and the IEEE standard 1149.1 signals are ignored. Pin with internal pulldown
device.
I = Input, O = Output, Z = High-impedance, S = Supply
