參數資料
型號: X9408WS24Z
廠商: INTERSIL CORP
元件分類: 數字電位計
英文描述: QUAD 10K DIGITAL POTENTIOMETER, 2-WIRE SERIAL CONTROL INTERFACE, 64 POSITIONS, PDSO24
封裝: 0.300 INCH, GREEN, PLASTIC, SOIC-24
文件頁數: 25/32頁
文件大小: 625K
代理商: X9408WS24Z
contents of the default data register (DR0) to the WCR.
The XDCP can be used as a three-terminal potentiometer or as a two terminal variable resistor in a
wide variety of applications including control, parameter adjustments, and signal processing.
Key Features
Four potentiometers in one package
64 resistor taps per potentiometer
2-wire serial interface
Wiper resistance, 40Ω typical at 5V
Four nonvolatile data registers for each pot
Nonvolatile storage of wiper position
Standby current < 1ìA max (total package)
VCC = 2.7V to 5.5V operation V+ = 2.7V to 5.5V V- = –2.7V to -5.5V
10kΩ, 2.5kΩ end to end resistances
High reliability
Endurance–100,000 data changes per bit per register
Register data retention–100 years
24 Ld SOIC, 24 Ld TSSOP, 24 Ld PDIP packages
Pb-free plus anneal available (RoHS compliant)
Related Documentation
Application Note(s):
A Compendium of Application Circuits for Intersil’s Digitally-Controlled (XDCP)
Potentiometers
A Primer on Digitally-Controlled Potentiometers
Achieving Excellent Audio Performance in Digitally Controlled Pots
Application of Intersil Digitally Controlled Potentiometers (XDCP) as Hybrid Analog/Digital
Feedback System Control Elements
Audio Xcellence: XDCP Signal Integrity Report (Audio Characterization Report)
DC/DC Module Trim with Digital Potentiometers
Designing Power Supplies Using Intersil’s XDCP Mixed Signal Products
Interfacing the X9408/X9418 XDCP to 8051 Microcontrollers
Power Supply and DC to DC Converter Control using Intersil Digitally Controlled
Potentiontiometers (XDCPs)
Putting Analog On The Bus
Shaft Encoder Drives Multiple Intersil Digitally Controlled Potentiontiometers (XDCPs)
Tone, Balance, and Volume Control using a Quad XDCP
Datasheet(s):
Quad Digitally Controlled (XDCP) Potentiometers
Technical Brief(s):
Converting a Fixed PWM to an Adjustable PWM
Evaluation Board(s):
Intersil_XDCP_Test_Utility_Manual_rev_3.2.3.pdf
LabView_XDCP_Software.zip
LabView_XDCP_Upgrade_3.2.3.zip
Readme_XicorLabVIEW_V3.2.3.txt
XDCP_Vref Evaluation Board Kit Documentation and Software
accessHW.zip
Technical Homepage:
Digitally Controlled Potentiometers (DCPs) and Capacitors (DCCs)
Precision Analog Homepage
Parametric Data
