WM8721
Product Preview
WOLFSON MICROELECTRONICS LTD
PP Rev 1.3 November 2000
14
The software control is given in Table 4.
REGISTER
ADDRESS
0000010
Left
Headphone
Out
BIT
LABEL
DEFAULT
DESCRIPTION
6:0
LHPVOL[6:0]
1111001
( 0dB )
Left Channel Headphone Output
Volume Control
1111111 = +6dB
. . 1dB steps down to
0110000 = -73dB
0000000 to 0101111 = MUTE
Left Channel Zero Cross detect
Enable
1 = Enable
0 = Disable
Left to Right Channel Headphone
Volume, Mute and Zero Cross Data
Load Control
1 = Enable Simultaneous Load of
LHPVOL[7:0] and LZCEN to
RHPVOL[7:0] and RZCEN
0 = Disable Simultaneous Load
Right Channel Headphone Output
Volume Control
1111111 = +6dB
. . 1dB steps down to
0110000 = -73dB
0000000 to 0101111 = MUTE
Right Channel Zero Cross Detect
Enable
1 = Enable
0 = Disable
Right to Left Channel Headphone
Volume, Mute and Zero Cross Data
Load Control
1 = Enable Simultaneous Load of
RHPVOL[7:0] and RZCEN to
LHPVOL[7:0] and LZCEN
0 = Disable Simultaneous Load
7
LZCEN
1
8
LRHPBOTH
0
6:0
RHPVOL[7:0]
1111001
( 0dB )
7
RZCEN
1
0000011
Right
Headphone
Out
8
RLHPBOTH
0
Table 4 Headphone Output Software Control
The recommended external components required to complete the application are shown in Figure 11.
AGND
R1
C1
AGND
HPOUT
Figure 11 Headphone Output Application Drawing
