參數資料
| 型號： | ATR0621P1-7FQY |
| 廠商： | ATMEL CORP |
| 元件分類： | 無繩電話/電話 |
| 英文描述： | TELECOM, CELLULAR, BASEBAND CIRCUIT, PBGA100 |
| 封裝： | 9 X 9 MM, 0.80 MM PITCH, ROHS COMPLIANT, LFBGA-100 |
| 文件頁數： | 28/31頁 |
| 文件大小： | 477K |
| 代理商： | ATR0621P1-7FQY |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁當前第28頁第29頁第30頁第31頁
6
4890C–GPS–10/06
ATR0621
EM_A16
C6
OUT
EM_A17
F8
OUT
EM_A18
B3
OUT
EM_A19
C5
OUT
EM_DA0
B6
I/O
PD
EM_DA1
B10
I/O
PD
EM_DA2
C7
I/O
PD
EM_DA3
C10
I/O
PD
EM_DA4
D10
I/O
PD
EM_DA5
E7
I/O
PD
EM_DA6
E9
I/O
PD
EM_DA7
B7
I/O
PD
EM_DA8
B8
I/O
PD
EM_DA9
A9
I/O
PD
EM_DA10
C8
I/O
PD
EM_DA11
B9
I/O
PD
EM_DA12
D8
I/O
PD
EM_DA13
C9
I/O
PD
EM_DA14
D9
I/O
PD
EM_DA15
E8
I/O
PD
GND
A1
IN
GND
A10
IN
GND
K1
IN
GND
K10
IN
LDOBAT_IN
K8
IN
LDO_EN
H7
IN
LDO_IN
K7
IN
LDO_OUT
H6
OUT
NRESET
C4
I/O
Open Drain PU
NSHDN
G7
OUT
NSLEEP
J6
OUT
NTRST
K2
IN
PD
P0
K9
I/O
PD
NANTSHORT
P1
G3
I/O
Configurable (PD)
GPSMODE0
AGCOUT1
Table 3-1.
ATR0621 Pinout (Continued)
Pin Name
LFBGA100
Pin Type
Pull Resistor
(Reset Value)(1)
Firmware Label
PIO Bank A
PIO Bank B
Notes:
1. PD = internal pull-down resistor, PU = internal pull-up resistor, OH = switched to Output High at reset
2. VBAT18 represent the internal power supply of the backup power domain, see section “Power Supply” on page 21
3. VDDIO is the supply voltage for the following GPIO pins: P1, P2, P8, P12, P14, P16, P17, P18, P19, P20, P21, P23, P24,
P25, P26, P27 and P29, see section “Power Supply” on page 21
4. VDD_USB is the supply voltage for the following USB pins: USB_DM and USB_DP, see section “Power Supply” on page
21. For operation of the USB interface, supply of 3.0V to 3.6V is required.
5. This pin is not connected
