1997 Oct 27
3
Philips Semiconductors
Product specification
UHF push-pull power transistor
BLV950
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
THERMAL CHARACTERISTICS
Note
1.
Total device; both sections equally loaded; thermal resistance is determined under specified RF operating
conditions.
SYMBOL
PARAMETER
CONDITIONS
MIN.
MAX.
UNIT
Per transistor section
V
CBO
V
CEO
V
EBO
I
C
I
C(AV)
P
tot
T
stg
T
j
collector-base voltage
collector-emitter voltage
emitter-base voltage
collector current (DC)
average collector current
total power dissipation (DC)
storage temperature
operating junction temperature
open emitter
open base
open collector
65
70
30
3
12
12
340
+150
200
V
V
V
A
A
W
°
C
°
C
T
mb
= 25
°
C
SYMBOL
PARAMETER
CONDITIONS
MAX.
UNIT
R
th j-mb
thermal resistance from junction to
mounting base
thermal resistance from mounting
base to heatsink
P
tot
= 340 W; T
mb
= 25
°
C; note 1
0.52
K/W
R
th mb-h
0.15
K/W
