LIN Controlled Alternator Voltage Regulator
Features:
Preliminary Data Sheet
IRVR101
9600 Baud Rate
10.7 to 16.0V Setpoint Control
Programmable Load Response
Control
Programmable Field Excitation
Full Diagnostic Capability
Self Excitation
Short Circuit Protected
EMI and ESD Immunity
Field Excitation, Temperature, and
Fault Status Feedback
< 200uA Standby Current
Description
The IRVR101 is an integral alternator voltage regulator that allows for external control of the setpoint voltage in
an automotive charging system where optimized alternator output control is desired. The setpoint control is
achieved using the Local Interconnect Network (LIN) serial communications protocol. Slew rate control and
filtering of the interface lines provide electromagnetic compatibility. The regulator consists of a control ASIC,
discrete low side power MOSFET (field driver), re-circulation diode, and passive components. The discrete
circuitry allows for optimal flexibility with respect to the alternator rotor circuit and charging system
requirements. The IRVR101 is characterized over the temperature range of –40
o
C to 150
o
C.
Design
The IRVR101 is manufactured using thick-film hybrid technology.
The hybrid circuit can be customized for your application to
optimize performance and reliability. The hybrid circuit can also
be assembled in a custom housing with an insert–molded lead-
frame specifically designed for flame-soldering or heavy wire
bonding. Thick-film hybrid technology offers reliable high
temperature operation with excellent parametric stability over the
entire operating temperature range. Resistor values are trimmed
within +/-1% using laser equipment that provides precise
calibration of voltage and current sensing circuitry. The control IC
is attached to the substrate using flip chip technology in order to
optimize space and reliability. Bare die is also used for the low
side field driver and re-circulation diode in order to optimize
space and heat transfer.
Voltage Sense
Phase Sense
F
B+
B+
RECTIFIER
ROTOR
STATOR
Circuitry
Driver
LIN
Diode
VOLTAGE REGULATOR
ALTERNATOR
P
Control
Field
Flyback
Custom Thick-film Hybrid Module
